Kinze 1100 Single Auger
Kinze 1100
Average price
$88,500
5+
sold in last year
General overview
Year
2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021
Country of manufacturing
United States
General specifications
Dimensions
Height
Width
Length
3,327 mm
~131 in
5,639 mm
~222 in
8,512 mm
~335.1 in
Unloading rate
1,400 L/min
Grain Cart Capacity
38,746 L
Required Engine Power
89.48 kW
Grain Cart Loaded Tongue Weight
2,268 kg
Grain Cart Empty Tongue Weight
1,542.21 kg
Grain Cart Auger Diameter
0.56 m
Flighting Thickness
1/4 in T edge; 7/16 in T root flighting
Hub Size/Spindle Diameter
20-bolt hub, 13.189 in bolt circle; 4.5 in spindle
Hydraulic Remotes Required
5 SCVs manual or 2 SCVs remote
Front/Rear Slopes
Steep front and rear slopes, 35°
Hopper Length
5.64 m
Hopper Width
3.66 m
Auger Side Reach Max
4.27 m
Auger Side Reach Min
2.74 m
Grain Cart Overall Transport Length
8.51 m
Additional specifications
Peak unloading rate
26,430 L/min
Capacity Heaped
45,811 cu(m)
Track size
914,4 mm
Tractor hydraulics requirements
5 SCVs for manual operation; 2 SCVs for remote joystick (closed-center system). Minimum hydraulic system pressure: 2,320 psi (≈16.0 MPa).
Total weight - empty
11,295 kg
Hitch weight - empty
1,792 kg
Hitch weight - loaded
2,850 kg
PSI capacity
324 kPa
Vertical auger
559 mm
Horizontal auger
508 mm
Gearbox
Direct-driven mechanical gearboxes (no further technical details published).
PTO speed
1,000
