John Deere Z540M Zero-Turn Mowers
John Deere Z540M
Average price
$3,390
5+
sold in last year
General overview
John Deere Z540M is a mower for routine grass-cutting and turf-maintenance work. It is powered by a Yanmar 3TNM74 diesel engine with 1 L (61 cu in) displacement and rated output of 18 kW (24 hp), giving the model a compact power class for managed grounds and general mowing tasks.
The model uses a Tuff Torq K90 transmission and reaches 8.5 km/h (5.3 mph) forward and 6 km/h (3.7 mph) in reverse. Its mid-mount, side-discharge mower deck measures 122 cm (4 ft), is built from stamped steel, and offers a height of cut range of 2.5 to 10.2 cm. The deck style is side discharge with optional MulchControlâ„¢ kit.
Year
2016, 2017, 2018, 2019, 2020
Country of manufacturing
United States
General specifications
Dimensions
Weight
Width
Height
Length
430 kg
~948 lb
1,190 mm
~46.9 in
1,300 mm
~51.2 in
1,940 mm
~76.4 in
Engine Power
24 hp
Brand and Model of The Engine
Kawasaki FS,730V
Transport speed
8.5 mph (13.7 kph) maximum forward; 4.0 mph (6.4 kph) maximum reverse
Cutting width
1.37 m
Cylinders
2
Additional specifications
Displacement
60.6 cu(in)
Transmission type
Tuff Torq K90
Fuel tank
19.7 L
Rated power
24 hp
Manufacturer
Yanmar
Fuel Type
Diesel
Charge System
40 amp
Battery Voltage
12 V
Cold Cranking Amp
500
Mower deck type
Mid-mount, side-discharge
Mower deck size
122 cm
Deck Construction
Stamped steel
Deck Thickness
3.4 mm
Mower deck style
Side discharge with optional MulchControlâ„¢ kit
Increment
0.64 cm
Deck blades number
3
Deck blades thickness
0.48 cm
Drive Wheels
Front: 13x5.00-6, Rear: 22x9.50-10
Travel Speed Forward
8.5 km/h
Travel Speed Reverse
6 km/h
Engine Model
3TNM74
Height of Cut Range
2.5 to 10.2 cm
Electro Magnetic with Brake
Electro-hydraulic
John Deere Z540M Zero-Turn Mowers Listings
$3,390
24 hp
3TNM74
Yanmar
220 hours
Redfield, United States
Compare John Deere Z540M Zero-Turn Mower to other zero-turn mowers
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere Z540M Zero-Turn Mower
24 hp
430 kg
1940 mm × 1190 mm × 1300 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere Z540M?
No confirmed market price is supplied. Check current listings and compare the mower’s condition, location, and configuration.
What are the key advantages of the John Deere Z540M?
The supplied specifications list a Yanmar 3TNM74 diesel engine rated at 17.9 kW (24 hp), a 122 cm (48 in) mid-mount side-discharge deck, and an optional MulchControlâ„¢ kit. It also has an electro-hydraulic brake and Tuff Torq K90 transmission.
What type of engine does the Z540M use?
The Z540M uses a Yanmar 3TNM74 diesel engine with 60.6 cu in displacement.
How much horsepower does the Z540M have?
The Z540M is rated at 17.9 kW (24 hp).
What fuel does the John Deere Z540M use?
The John Deere Z540M uses diesel fuel.
What jobs is this Mowers best suited for?
The supplied data identifies it as a mower with a 122 cm (48 in) mid-mount, side-discharge deck and an optional MulchControlâ„¢ kit. It is suited to mowing work where side discharge or optional mulching is needed.
What is the expected lifespan of the Z540M?
The supplied data does not confirm an expected lifespan. Inspect maintenance records, engine condition, deck wear, transmission operation, tires, and the brake system when evaluating a mower.
What should a buyer check when purchasing a used Mowers?
Check service records, diesel engine starting and operation, fuel-system condition, deck damage and blade wear, cut-height adjustment, transmission response, brake operation, tire condition, and battery and charging-system function.
