John Deere Z515E Zero-Turn Mowers
John Deere Z515E
Average price
$3,795
5+
sold in last year
General overview
The John Deere Z515E is a zero-turn mower for mowing maintained turf, especially where maneuverability matters around obstacles and landscaped features. It uses a Kawasaki M44 Extended Life Series (ELS) gasoline engine rated at 18 kW (24 hp), giving the model a compact power class for routine grass cutting.
The mower is built around a unitized hydrostatic drivetrain with Tuff Torq TZT7-D dual transmissions and 2WD (hydrostatic zero-turn) drive. A 1,372 mm (4 ft 6 in) Accel Deepâ„¢ deck, side discharge setup, 25.4 mm (1 in) height-of-cut range, and 12 km/h (7.5 mph) forward travel speed define its working range, while the V-belt PTO drive supports the cutting system.
Year
2021, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
1,953 mm
~76.9 in
1,806 mm
~71.1 in
1,370 mm
~53.9 in
Engine Power
24 hp
Displacement
cu(m)
Fuel tank
17 L
Electrical system type
Alternator
Brand and Model of The Engine
M44 Extended Life Series (ELS)
Transport speed
0-8 mph (0-12.9 km/h)
Rated power
24 hp
Manufacturer
Kawasaki
Battery Voltage
12
Cold Cranking Amp
300
Mower deck type
Accel Deepâ„¢
Mower deck size
1,372 mm
Deck Construction
Stamped steel (heavy-duty frame tubing, E-coat/primer/powder paint)
Deck Thickness
2 mm
Mower deck style
Side discharge, optional MulchControlâ„¢ kit mm
Deck blades number
3
Deck blades thickness
3 mm
Drive Wheels
Dual wheel motors, integrated with Kanzaki KPU10A pumps (1-in. axle diameter, ~10 cc displacement)
Caster Wheel Type
13x6.5-6 (front caster tires), sealed ball bearings
Tires
22x9.5-10 (rear drive tires)
Drivetrain
Unitized hydrostatic (Tuff Torq TZT7-D, dual transmissions)
Hydraulic Pumps
cu(cm)
Hydraulic Capacity
1 L
Travel Speed Forward
12 km/h
Travel Speed Reverse
6 km/h
Engine Model
M44 Extended Life Series (ELS)
Height of Cut Range
25,4 mm
Electro Magnetic with Brake
Electric, 105 lb.-ft. (142.4 Nm) with brake
PTO Drive
V-belt
Cutting width
1.37 m
Blade tip speed
145 km/h
Cylinders
V-twin
Tire Ply Rating
Drive tires (22x9.5-10): 10-ply load range C (440 kg/axle at 34 psi); Caster (13x6.5-6): 4-ply load range B (200 kg/tire at 20 psi)
Additional specifications
Fuel capacity
17 L
Drive type
2WD (hydrostatic zero-turn)
Fuel Type
gasoline
John Deere Z515E Zero-Turn Mowers Listings
$3,795
24 hp
M44 Extended Life Series (ELS)
Kawasaki
64 hours
Isanti, United States
Compare John Deere Z515E Zero-Turn Mower to other zero-turn mowers
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere Z515E?
No confirmed market price is supplied. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere Z515E?
Key listed features include 17.9 kW (24 hp), a 1,372 mm (54 in) Accel Deepâ„¢ mower deck, hydrostatic zero-turn 2WD, and a 17 L (4.5 US gal) gasoline fuel capacity.
What type of engine does the Z515E use?
The Z515E uses a Kawasaki M44 Extended Life Series (ELS) engine.
How much horsepower does the Z515E have?
The Z515E has 24 hp.
What fuel does the John Deere Z515E use?
The John Deere Z515E uses gasoline.
What jobs is this Mowers best suited for?
The supplied data identifies this machine as a mower with a 1,372 mm (54 in) side-discharge Accel Deepâ„¢ deck and an optional MulchControlâ„¢ kit. It is suited to mowing work where those deck configurations are needed.
What is the expected lifespan of the Z515E?
The supplied data does not confirm an expected service life. Lifespan depends on maintenance, operating conditions, and the condition of the engine, deck, drivetrain, and other components.
What should a buyer check when purchasing a used Mowers?
Check the engine, hydrostatic drivetrain, mower deck, blades, belts, tires, battery, and safety controls. Inspect for leaks, corrosion, deck damage, uneven cutting, and signs of poor maintenance; test operation before purchase.
