John Deere XUV855M S4 UTVs
John Deere XUV855M S4
5+
sold in last yearGeneral overview
John Deere XUV855M S4 is a farm utility vehicle intended for transport and general off-road work. It is powered by a 16 kW (22 hp) 4-stroke diesel, fuel injected engine supplied by Yanmar, and paired with a Continuously Variable Transmission (CVT) with high, low and reverse range. The model was produced in 2023 and 2024 in the United States.
The drivetrain includes an on-demand true four-wheel drive system, positive locking, mechanically actuated (hand-operated) traction assist, and a two speed, oil bath final drive. With a capacity of 454 kg (1,000 lb), towing capacity of 680 kg (1,500 lb), and a 2,896 mm (9 ft 6 in) wheelbase, it is configured for hauling and utility tasks.
Year
2023, 2024
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
3,911 mm
~154 in
1,903 mm
~74.9 in
1,571 mm
~61.9 in
Engine Power
22 hp
Engine type
4-stroke diesel, fuel injected
Displacement
cu(m)
Tires front
27x9-R14 Maxxis® Bighorn® 2.0 extreme terrain radials on steel or alloy wheels
Transmission type
Continuously Variable Transmission (CVT) with clutch enclosure
Electrical system type
55
Fuel capacity
27 L
Cooling system
5.5 L
Wheelbase
2,896 mm
Box length
1,143 mm
Manufacturer
Yanmar
Capacity (weight)
454 kg
Towing capacity
680 kg
Brakes type
Four-wheel hydraulic disc
Park brake
Driveline, internal wet multi-disc, hand operated
Drivetrain
Continuously Variable Transmission (CVT) with high, low and reverse range
Final drive
Two speed, oil bath
Four wheel drive
On-demand true four-wheel drive system
Traction assist
Positive locking, mechanically actuated (hand-operated)
Descent control
Yes
Cab Height
305 mm
Final Drive
Park, high, low, neutral, reverse transaxle
Boom Width
1,320 mm
Rakes Wheel tread
27 mm
Cargo box dimensions
1,143 x 305 x 1,320
Cargo box capacity (weight)
454 kg
Front suspension
Fully independent dual A-arm with adjustable coils; 203 mm (8 in.) of travel
Rear suspension
Fully independent dual A-arm with adjustable coils and sway bar; 229 mm (9 in.) of travel
Additional specifications
Color
12
John Deere XUV855M S4 UTVs Listings
Looking for John Deere XUV855M S4 UTVs?
See similar listingsCompare John Deere XUV855M S4 UTV to other utvs
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere XUV855M S4?
No confirmed market price is supplied. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere XUV855M S4?
Listed features include a 4-stroke diesel, fuel-injected Yanmar engine, Continuously Variable Transmission (CVT) with high, low and reverse range, on-demand true four-wheel drive, positive locking traction assist, hydraulic disc brakes, and towing capacity of 680 kg (1,499 lb).
What type of engine does the XUV855M S4 use?
The XUV855M S4 uses a Yanmar 4-stroke diesel, fuel-injected engine.
How much horsepower does the XUV855M S4 have?
The XUV855M S4 has 16.4 kW (22 hp) of engine power.
What fuel does the John Deere XUV855M S4 use?
The John Deere XUV855M S4 uses diesel fuel. Its fuel capacity is 27 L (7.1 US gal).
What jobs is this ATVs and Gators best suited for?
The supplied specifications support use for hauling and towing tasks where four-wheel drive and traction assist are beneficial. It has a capacity of 454 kg (1,001 lb) and a towing capacity of 680 kg (1,499 lb).
What is the expected lifespan of the XUV855M S4?
The supplied data does not confirm an expected service life. Inspect maintenance records, engine condition, drivetrain operation, brakes, tires, and signs of wear before purchase.
What should a buyer check when purchasing a used ATVs and Gators?
Check maintenance records, engine starting and operation, transmission ranges, four-wheel-drive and traction-assist function, brakes, tires, cargo area, towing equipment, and signs of leaks, damage, or excessive wear.
