John Deere XUV590M S4 UTVs
John Deere XUV590M S4
5+
sold in last yearGeneral overview
John Deere XUV590M S4 is a farm utility vehicle for hauling tasks on agricultural properties and other work areas. It is powered by a 24 kW (32 hp) 0.6 L 4-cycle gas, inline-twin, electronic fuel injection (EFI), overhead valves (OHV) engine. The model is manufactured in the United States and has a 28 L (7 US gal) fuel capacity.
A Continuously Variable Transmission (CVT) with clutch enclosure works with a 4x4 drive type and dash switch actuated four-wheel drive system. Its capacity (weight) is 227 kg (500 lb), towing capacity is 680 kg (1,500 lb), and the 2,743 mm (9 ft) wheelbase and 820 mm (32 in) box length help define the chassis and cargo layout. Limited slip front differential and Positive locking, switch actuated rear differential lock add traction control for uneven ground.
Year
2019, 2020, 2022, 2023
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
3,658 mm
~144 in
1,880 mm
~74 in
1,435 mm
~56.5 in
Engine Power
32 hp
Engine type
4-cycle gas, inline-twin, electronic fuel injection (EFI), overhead valves (OHV)
Displacement
0,586 cu(m)
Tires front
25x8-12 Terra Hawk all-terrain on steel wheels
Transmission type
Continuously Variable Transmission (CVT) with clutch enclosure
Electrical system type
65
Alternator output
Green/yellow, olive/black, TRUETIMBER Kanati camo
Fuel capacity
28 L
Cooling system
6.6 L
Wheelbase
2,743 mm
Drive type
4x4
Box length
820 mm
Battery Voltage
12 V DC outlet
Caster Wheel Type
Terra Hawk all-terrain
Volume
250 L
Capacity (weight)
227 kg
Towing capacity
680 kg
Brakes type
196 mm ventilated four-wheel stainless steel disc brakes with hydraulic 34.93 mm diameter twin-piston calipers
Park brake
Park in-transmission
Drivetrain
Continuously Variable Transmission (CVT) with clutch enclosure
Final drive
Park, high, low, neutral, reverse transaxle
Four wheel drive
Dash switch actuated four-wheel drive system
Traction assist
Limited slip front differential, Positive locking, switch actuated rear differential lock
Descent control
No
Cab Height
297 mm
Final Drive
Park, high, low, neutral, reverse transaxle
Boom Width
1,209 mm
Rakes Wheel tread
25x10-12 Terra Hawk all-terrain on steel wheels mm
Cargo box dimensions
32.3 x 47.6 x 11.7
Cargo box capacity (weight)
227 kg
Front suspension
Fully independent dual A-arm with adjustable coil-over shocks, 203 mm (8 in.) travel, anti-roll bar
Rear suspension
Fully independent with lower A-arm and upper camber link with adjustable coil-over shocks, 203 mm (8 in.) travel
Additional specifications
Color
12
John Deere XUV590M S4 UTVs Listings
Looking for John Deere XUV590M S4 UTVs?
See similar listingsCompare John Deere XUV590M S4 UTV to other utvs
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere XUV590M S4?
No confirmed market price is supplied for the John Deere XUV590M S4. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere XUV590M S4?
Listed features include 4x4, dash-switch-actuated four-wheel drive, a limited-slip front differential, a switch-actuated rear differential lock, CVT, and hydraulic four-wheel disc brakes. It also has 680 kg (1,499 lb) towing capacity and 227 kg (500 lb) weight capacity.
What type of engine does the XUV590M S4 use?
The XUV590M S4 uses a 4-cycle gas, inline-twin engine with electronic fuel injection (EFI) and overhead valves (OHV).
How much horsepower does the XUV590M S4 have?
The XUV590M S4 is rated at 23.9 kW (32 hp).
What fuel does the John Deere XUV590M S4 use?
The supplied specifications identify the engine as a 4-cycle gas engine. They do not provide a more specific fuel requirement.
What jobs is this ATVs and Gators best suited for?
The supplied data does not identify specific intended jobs. Its listed 4x4 system, traction-assist features, 680 kg (1,499 lb) towing capacity, and 227 kg (500 lb) weight capacity may be relevant when assessing task requirements.
What is the expected lifespan of the XUV590M S4?
The supplied information does not confirm an expected lifespan for the XUV590M S4. Inspect maintenance history, engine operation, drivetrain function, brakes, tires, and signs of damage when evaluating a unit.
What should a buyer check when purchasing a used ATVs and Gators?
Check service records, engine starting and operation, CVT and transaxle shifting, four-wheel-drive engagement, differential-lock operation, brake condition, tire wear, steering, chassis damage, and fuel-system condition. Confirm that the equipment’s configuration and capacities match the intended work.
