John Deere XUV865M UTVs
John Deere XUV865M
Average price
$23,940
5+
sold in last year
General overview
John Deere XUV865M is a utility vehicle in the ATVs and Gators category, designed for farm transport and other worksite travel. It uses a 17 kW (22.8 hp) 4-cycle diesel engine and a Continuously Variable Transmission (CVT) with clutch enclosure, giving it a drivetrain suited to low-speed utility work and changing terrain.
The model is built for hauling and towing, with a capacity of 454 kg (1,000 lb) and a towing capacity of 1,814 kg (4,000 lb). It also includes a dash switch actuated four-wheel drive system, a limited slip front differential, descent control, and a final drive with park, high, low, neutral, reverse transaxle for controlled operation.
Year
2022, 2023, 2024
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
1,618 mm
~63.7 in
1,981 mm
~78 in
3,228 mm
~127.1 in
877 kg
~1,933.5 lb
Engine Power
22.8 hp
Cooling system
4.9 L
Cargo box dimensions
1,143 x 305 x 1,320 mm (45 x 12 x 52 in.)
Cargo box capacity (weight)
454 kg
Front suspension
Fully independent dual A-arm with adjustable coils; 203 mm (8 in.) of travel
Rear suspension
Fully independent dual A-arm with adjustable coils and sway bar; 229 mm (9 in.) of travel
Additional specifications
Engine type
4-cycle diesel
Displacement
854 cu(cm)
Transmission type
Continuously Variable Transmission (CVT) with clutch enclosure
Fuel capacity
42.4 L
Wheelbase
2,146 mm
Battery Voltage
Capacity (weight)
454 kg
Towing capacity
1,814 kg
Brakes type
Front/rear hydraulic disc with twin piston front calipers
Park brake
Park in-transmission
Color
E, M, and R Trim: Green and yellow, TrueTimber® KANATI®, olive and black Signature Edition: Green and yellow
Alternator
55 amp
Power port
12 V
Four wheel drive
Dash switch actuated four-wheel drive system
Traction assist
Limited slip front differential, Positive locking,switch actuated rear differential lock
Descent control
Yes
Battery Capacity
12 V 480 CCA
Final Drive
Park, high, low, neutral, reverse transaxle
Front Tire Configuration
25x9-12 Terra Hawk all-terrain on steel wheels
Rear Tire Configuration
25x11-12 Terra Hawk all-terrain on steel wheels. Only available on E-trim
John Deere XUV865M UTVs Listings
$23,940
22.8 hp
4-cycle diesel
454 kg
5429 hours
Wasco, United States
Compare John Deere XUV865M UTV to other utvs
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere XUV865M?
No confirmed market price is supplied for the John Deere XUV865M. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere XUV865M?
Listed features include a 4-cycle diesel engine, 1,814 kg (3,999 lb) towing capacity, 454 kg (1,001 lb) weight capacity, dash-switch four-wheel drive, differential locking, descent control, and hydraulic disc brakes.
What type of engine does the XUV865M use?
The XUV865M uses a 4-cycle diesel engine with 854 cc displacement.
How much horsepower does the XUV865M have?
The XUV865M engine is rated at 17 kW (22.8 hp).
What fuel does the John Deere XUV865M use?
The John Deere XUV865M uses diesel fuel. Its fuel capacity is 42.4 L (11.2 US gal).
What jobs is this ATVs and Gators best suited for?
The supplied specifications do not confirm specific job applications. Its listed towing capacity, weight capacity, four-wheel drive, traction assist, descent control, and all-terrain tires may be relevant when assessing work requirements.
What is the expected lifespan of the XUV865M?
The supplied data does not provide an expected lifespan for the XUV865M. Assess service records, engine condition, transmission operation, brakes, tires, battery, and signs of wear before purchase.
What should a buyer check when purchasing a used ATVs and Gators?
Check service records, engine starting and operation, CVT response, four-wheel-drive and differential-lock function, brakes, tires, steering, suspension, battery, electrical ports, towing equipment, and evidence of leaks or damage.
