John Deere XUV590M UTVs
John Deere XUV590M
5+
sold in last yearGeneral overview
John Deere XUV590M is an ATV and Gator utility vehicle used for work around farms and other property where transport, hauling, and towing are part of daily operations. It is powered by a 24 kW (32 hp) 4-cycle gas, inline-twin, electronic fuel injection (EFI), overhead valves (OHV) engine with 0.6 L displacement.
The XUV590M uses a Continuously Variable Transmission (CVT) with clutch enclosure and a final drive with park, high, low, neutral, reverse transaxle. Its dash switch actuated four-wheel drive system includes a limited slip front differential, plus locking rear differential and positive locking, switch actuated rear differential lock. Towing capacity is 680 kg (1,500 lb), and capacity (weight) is 227 kg (500 lb).
Year
2022, 2023, 2024
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
1,435 mm
~56.5 in
1,867 mm
~73.5 in
2,870 mm
~113 in
676 kg
~1,490.3 lb
Engine Power
32 hp
Cooling system
3.8 L
Descent control
No
Cargo box dimensions
820 x 1,209 x 297
Cargo box capacity (weight)
227 kg
Front suspension
Fully independent dual A-arm with adjustable coil-over shocks, 203 mm (8 in.) travel, anti-roll bar
Rear suspension
Fully independent with lower A-arm and upper camber link with adjustable coil-over shocks, 203 mm (8 in.) travel
Additional specifications
Engine type
4-cycle gas, inline-twin, electronic fuel injection (EFI), overhead valves (OHV)
Displacement
586 cu(cm)
Transmission type
Continuously Variable Transmission (CVT) with clutch enclosure
Fuel capacity
28 L
Wheelbase
1.86 m
Battery Voltage
12 V 340 CCA
Volume
252 L
Capacity (weight)
227 kg
Dimensions
mm
Towing capacity
680 kg
Brakes type
196 mm (7.7 in.) ventilated four-wheel stainless steel disc brakes with hydraulic 34.93 mm (1.375 in.) diameter twin-piston calipers
Park brake
Park in-transmission
Color
Green & Yellow, Camouflage, Olive & Black
Alternator
65 amp
Power port
12 V
Four wheel drive
Dash switch actuated four-wheel drive system with limited slip front differential, plus locking rear differential
Traction assist
Positive locking, switch actuated rear differential lock
Battery Capacity
12 V 340 CCA
Final Drive
Park, high, low, neutral, reverse transaxle
Battery Type
Front Tire Configuration
25x8-12 Terrahawk AT (All Terrain) 4-ply rating steel wheels, various colors
Rear Tire Configuration
26x8-14 Maxxis® Bighorn® 2.0 6-ply rating steel wheels, various colors
John Deere XUV590M UTVs Listings
Looking for John Deere XUV590M UTVs?
See similar listingsCompare John Deere XUV590M UTV to other utvs
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere XUV590M?
No confirmed market price is supplied. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere XUV590M?
Listed features include 23.9 kW (32 hp), EFI, a Continuously Variable Transmission (CVT), switch-actuated four-wheel drive, a locking rear differential, 227 kg (500 lb) weight capacity, and 680 kg (1,499 lb) towing capacity.
What type of engine does the XUV590M use?
The XUV590M uses a 4-cycle gas, inline-twin engine with electronic fuel injection (EFI) and overhead valves (OHV). Its displacement is 586 cc.
How much horsepower does the XUV590M have?
The XUV590M has 23.9 kW (32 hp) of engine power.
What fuel does the John Deere XUV590M use?
The XUV590M uses gas. Its fuel capacity is 28 L (7.4 US gal).
What jobs is this ATVs and Gators best suited for?
The supplied information does not identify specific best-suited jobs. Its listed 227 kg (500 lb) weight capacity and 680 kg (1,499 lb) towing capacity may be relevant when matching it to work requirements.
What is the expected lifespan of the XUV590M?
The supplied data does not provide an expected service-life estimate. Inspect maintenance records, engine condition, transmission operation, brakes, tires, battery, and differential functions when evaluating a unit.
What should a buyer check when purchasing a used ATVs and Gators?
Check maintenance records, engine starting and operation, CVT function, four-wheel drive and differential locks, brakes, tires, towing equipment, battery, and signs of leaks, damage, or corrosion. Confirm that the listed capacity and configuration meet your needs.
