John Deere N560F-C850T Air Drills and Seeders
John Deere N560F-C850T
5+
sold in last yearGeneral overview
John Deere N560F-C850T is an air drill and seeder attachment used for field seeding and dry fertilizer placement in crop production. It combines ProSeries disk openers with rank lock-up and has an 18,300 mm (60 ft) working width, giving the model a large coverage profile for wide-pass planting operations.
Standard features include TruSet in-cab downforce, RelativeFlow blockage monitoring, Double-Shoot capable operation, ProSeries quick-change blades, and AccuRate stainless-steel electric meters (cart) with ActiveCal and tank scales (cart). The machine is arranged in 3 ranks with 1,341 mm (4 ft 5 in) space between ranks and 254 mm (10 in) row spacing. Seed placement is handled by ProSeries disk opener, 457 mm diameter, 7° seed angle, while dry fertilizer uses ProSeries disk opener for dry fertilizer, 457 mm diameter, 5° or 7° angle.
Year
2024, 2025
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
25,180 mm
~991.3 in
5,200 mm
~204.7 in
6,160 mm
~242.5 in
Seed-tank capacity
22,953 cu(m)
Additional specifications
Width
18,300 mm
Row Spacing
254 mm
Openers system
ProSeries disk openers with rank lock-up
Standard features
TruSet in-cab downforce; RelativeFlow blockage monitoring; Double-Shoot capable; ProSeries quick-change blades; AccuRate stainless-steel electric meters (cart) with ActiveCal and tank scales (cart).
Number of ranks
3
Space between ranks
1,341 mm
Seed spacing
254 mm
Fertilizer spacing
508 mm
Seed openers
ProSeries disk opener, 457 mm diameter, 7° seed angle
Fertilizer openers
ProSeries disk opener for dry fertilizer, 457 mm diameter, 5° or 7° angle
John Deere N560F-C850T Air Drills and Seeders Listings
Looking for John Deere N560F-C850T Air Drills and Seeders?
See similar listingsCompare John Deere N560F-C850T Air Drills and Seeder to other air drills and seeders
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere N560F-C850T Air Drills and Seeder
22953 cu(m)
25180 mm × 6160 mm × 5200 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere N560F-C850T?
No confirmed market price is supplied for the John Deere N560F-C850T. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere N560F-C850T?
Key features include ProSeries disk openers with rank lock-up, TruSet in-cab downforce, RelativeFlow blockage monitoring, Double-Shoot capability, quick-change blades, and AccuRate stainless-steel electric meters with ActiveCal and tank scales on the cart.
What type of engine does the N560F-C850T use?
The supplied specifications do not confirm an engine type for the N560F-C850T.
How much horsepower does the N560F-C850T have?
The supplied specifications do not confirm a horsepower rating for the N560F-C850T.
What fuel does the John Deere N560F-C850T use?
The supplied specifications do not confirm the fuel type for the John Deere N560F-C850T.
What jobs is this Air Drills and Seeders best suited for?
This air drill and seeder is suited to seed placement and dry-fertilizer application. Its Double-Shoot capability, ProSeries disk openers, 254 mm (10 in) row spacing, and separate seed and fertilizer opener arrangements support those field operations.
What is the expected lifespan of the N560F-C850T?
No expected service-life figure is supplied for the N560F-C850T. Lifespan depends on maintenance, operating conditions, storage, and wear of components such as openers, blades, meters, and monitoring systems.
What should a buyer check when purchasing a used Air Drills and Seeders?
Inspect opener discs and quick-change blades for wear, verify rank lock-up operation, and test TruSet downforce and RelativeFlow monitoring. Check electric meters, ActiveCal, tank scales, hoses, seed and fertilizer delivery components, and the condition of the frame and connections.
