John Deere N560F-C850 Air Drills and Seeders
John Deere N560F-C850
Average price
$649,220
5+
sold in last year
General overview
John Deere N560F-C850 is an air drill and seeder for field seeding and fertilizer placement in crop production. It uses a ProSeriesâ„¢ opener (rank lock-up) with active hydraulic downforce and a three-rank layout. The machine is arranged with 72 openers and 254 mm (10 in) row spacing, giving it a wide field-working setup for large-acreage planting.
The model spans 18,300 mm (60 ft) and has front, middle, and rear ranks spaced 1,341 mm (4 ft 5 in) apart. Standard features include TruSet™ in-cab downforce, RelativeFlow™ blockage monitoring, ProSeries™ Quick Change Blade enhancement, Semi-pneumatic depth control, and an in-furrow press wheel. Seed openers use a 45.7 cm (18 in.) disk with a single beveled-edge blade set at 7°, while fertilizer placement is handled separately through a dry fertilizer opener at 5° or 7° angle.
Year
2023, 2024
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
11,600 mm
~456.7 in
5,200 mm
~204.7 in
5,700 mm
~224.4 in
Seed-tank capacity
29,953 cu(m)
Additional specifications
Width
18,300 mm
Row Spacing
254 mm
Openers system
ProSeriesâ„¢ opener (rank lock-up); active hydraulic downforce; front, middle, and rear ranks
Standard features
TruSetâ„¢ in-cab downforce, RelativeFlowâ„¢ blockage monitoring, ProSeriesâ„¢ Quick Change Blade enhancement, Semi-pneumatic depth control, In-furrow press wheel
Number of openers
72
Number of ranks
3
Space between ranks
1,341 mm
Seed spacing
254 mm
Fertilizer spacing
508 mm
Seed openers
ProSeries™ opener; 45.7 cm (18 in.) disk; single blade with beveled edge; seed at 7°
Fertilizer openers
Separate fertilizer placement (SFP); dry fertilizer opener at 5° or 7° angle; separate fertilizer rank
John Deere N560F-C850 Air Drills and Seeders Listings
$649,220
10"
ProSeriesâ„¢ opener (rank lock-up); active hydraulic downforce; front, middle, and rear ranks
TruSetâ„¢ in-cab downforce, RelativeFlowâ„¢ blockage monitoring, ProSeriesâ„¢ Quick Change Blade enhancement, Semi-pneumatic depth control, In-furrow press wheel
Washburn, United States
Compare John Deere N560F-C850 Air Drills and Seeder to other air drills and seeders
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere N560F-C850 Air Drills and Seeder
29953 cu(m)
11600 mm × 5700 mm × 5200 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere N560F-C850?
No confirmed market price is supplied for the John Deere N560F-C850. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the John Deere N560F-C850?
Key listed features include 72 ProSeriesâ„¢ openers, TruSetâ„¢ in-cab downforce, RelativeFlowâ„¢ blockage monitoring, and separate fertilizer placement. It also has three ranks, semi-pneumatic depth control, and an in-furrow press wheel.
What type of engine does the N560F-C850 use?
The supplied specifications do not confirm an engine type for the John Deere N560F-C850.
How much horsepower does the N560F-C850 have?
The supplied specifications do not confirm a horsepower rating for the John Deere N560F-C850.
What fuel does the John Deere N560F-C850 use?
The supplied specifications do not confirm the fuel type for the John Deere N560F-C850.
What jobs is this Air Drills and Seeders best suited for?
The listed configuration supports seeding with separate dry-fertilizer placement. Its 72 openers, three-rank layout, 254 mm (10 in) row spacing, and blockage monitoring are relevant for field seeding operations requiring seed and fertilizer placement.
What is the expected lifespan of the N560F-C850?
The supplied data does not provide an expected service life. Lifespan depends on maintenance, operating conditions, and wear of openers, disks, press wheels, hydraulic components, and monitoring equipment.
What should a buyer check when purchasing a used Air Drills and Seeders?
Inspect opener disks, blades, press wheels, rank lock-up, depth control, hydraulic downforce, and fertilizer-placement components. Test the RelativeFlowâ„¢ blockage monitoring and TruSetâ„¢ in-cab downforce, and check the seed tank, hoses, and frame for wear or damage.
