John Deere DB80 Row Crop Planters — Drawn
John Deere DB80
Average price
$398,500
5+
sold in last year
General overview
John Deere DB80 is an air drill and seeder attachment for field planting operations. It is built for agricultural seed placement and was produced in 2010 in the United States. The model carries a 3,524 L (100 bu) seed tank, giving it a capacity suited to planting work across prepared fields.
The DB80 uses Tru‑Vee™ double-disc openers, with 36 seed openers arranged in one rank. Row spacing is 762 mm (30 in), and the specified opener layout defines a single-rank planting pattern for seeding applications. The Tru‑Vee double-disc units are the seed openers used on this model, supporting row placement and seed delivery across the implement.
Year
2010, 2022
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
4,900 mm
~192.9 in
3,700 mm
~145.7 in
15,200 mm
~598.4 in
15,876 kg
~35,000.6 lb
Seed-tank capacity
100 bu
Seed Hopper Capacity
0.062 bu per row-unit hopper
Planter – Number of rows
48 rows
Base Seed Meter
Vacuum
Planter Tire Base
445/50R22.5 center-frame tires with 31-13.5x15 or 31-13.5x16.5 wing tires
Row Units Type
ExactEmerge or MaxEmerge 5e row units
Row Units Opener
Tru-Vee double disk
Markers Type
Automatic alternating or independent control
Additional specifications
Row Spacing
762 mm
Openers system
Tru‑Vee™ double-disc openers
Standard features
3‑section flex-fold frame; hydraulic variable‑rate drive; 3‑section shutoff; pneumatic downforce; CCS; electric drive & EPG; vDrive, SpeedTube & DeltaForce retrofits; RowCommand; liquid fertilizer system; markers; scrapers; SeedStar XP; DeltaForce; spoke & Mudsmith closing wheels
Number of openers
36
Number of ranks
1
Space between ranks
762 mm
Seed openers
Tru‑Vee double-disc units
John Deere DB80 Row Crop Planters — Drawn Listings
$398,500
3‑section flex-fold frame; hydraulic variable‑rate drive; 3‑section shutoff; pneumatic downforce; CCS; electric drive & EPG; vDrive, SpeedTube & DeltaForce retrofits; RowCommand; liquid fertilizer system; markers; scrapers; SeedStar XP; DeltaForce; s...
100 bu
Tru‑Vee™ double-disc openers
Monticello, United States
Compare John Deere DB80 Row Crop Planters — Drawn to other row crop planters — drawn
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere DB80 Row Crop Planters — Drawn
100 bu
15876 kg
15200 mm × 4900 mm × 3700 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere DB80?
No confirmed market price is supplied for the John Deere DB80. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere DB80?
The supplied specifications list a 100 bu seed-tank capacity, 36 openers, and Tru‑Vee™ double-disc openers. Row spacing is 762 mm (30 in), with one rank and 762 mm (30 in) between ranks.
What type of engine does the DB80 use?
The supplied data does not confirm an engine type for the John Deere DB80.
How much horsepower does the DB80 have?
The supplied data does not confirm a horsepower rating for the John Deere DB80.
What fuel does the John Deere DB80 use?
The supplied data does not confirm a fuel type for the John Deere DB80.
What jobs is this Air Drills and Seeders best suited for?
The John Deere DB80 is identified as an Air Drills and Seeders attachment. Its listed configuration includes 36 openers, Tru‑Vee™ double-disc openers, and 762 mm (30 in) row spacing.
What is the expected lifespan of the DB80?
The supplied data does not provide an expected service life for the John Deere DB80. Inspect overall condition, maintenance history, seed-tank condition, and opener wear when evaluating a unit.
What should a buyer check when purchasing a used Air Drills and Seeders?
Check the seed tank, Tru‑Vee double-disc units, opener condition, and consistency of the 36-openers configuration. Review maintenance history and inspect for wear, damage, missing parts, and operational issues before purchase.
