John Deere 9560RT Tracked Tractors (2 Tracks)
John Deere 9560RT
Average price
$165,300
5+
sold in last year
General overview
John Deere 9560RT is a tracked tractor from the 2012-2014 production years, built in the United States for high-power farm field work. It uses a diesel engine with a displacement of 13.5 L (823 cu in) and is rated at 395 kW (538 hp), placing it in a high-horsepower class for demanding pulling and field operations.
It is equipped with an 18-speed full power shift transmission, Tier IV emissions level, and a 2 Tracks configuration. For implement work, the tractor has a rear hitch category of Cat-4N/4, a closed-center pressure/flow compensated hydraulic system with a pump rated output of 181.7 L/min (48 gpm), 4 to 6 rear selective control valves with electronic control, maximum lift capacity behind lift points 6,940 kg (15,300 lb), and PTO ratings of 261 kW (354.5 hp) maximum and 234 kW (319 hp) rated at 1000 rpm.
Year
2012, 2013, 2014
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
3,450 mm
~135.8 in
3,400 mm
~133.9 in
6,010 mm
~236.6 in
20,371 kg
~44,910.4 lb
Tire or Track Type
2 Tracks
Engine Power
538 hp
Track Width
0.76 m
Additional specifications
Emission standard level
Tier IV
Engine type
Diesel
Displacement
823 cu(in)
Maximum PTO power
354.45 hp
Rated PTO power
319 hp
Speeds
1,000 rpm
Transmission type
18-speed full power shift
Rear hitch category (SAE designation)
Cat-4N/4
Maximum lift capacity behind lift points
6,940 kg
Fuel tank
1,286.9 L
Cab glass area
6.52 sq(m)
Hydraulic system type
Closed-center pressure/flow compensated
Pump rated output
181.7 L/min
Number of rear selective control valves
4 to 6
SCV control
Electronic
Sensing type
Electro-hydraulic draft sensing
Tires rear
Width: 76 cm
Transmission Speeds
John Deere 9560RT Tracked Tractors (2 Tracks) Listings
$86,400
2 Tracks
538 hp
Power Shift
11253 hours
Imperial, United States
$199,900
1286.9 L
Closed-center pressure/flow compensated
6.52 sq(m)
3630 hours
Perry, United States
$209,600
538 hp
2 Tracks
Tier IV
4305 hours
Flagler, United States
Compare John Deere 9560RT Tracked Tractors (2 Tracks) to other tracked tractors (2 tracks)
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 9560RT Tracked Tractors (2 Tracks)
538 hp
20371 kg
6010 mm × 3450 mm × 3400 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 9560RT?
No confirmed market price is supplied for the John Deere 9560RT. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere 9560RT?
Listed features include 2 Tracks, 401.2 kW (538 hp) engine power, an 18-speed full power shift transmission, a closed-center pressure/flow compensated hydraulic system, and 4 to 6 electronically controlled rear selective control valves.
What type of engine does the 9560RT use?
The 9560RT uses a Diesel engine with 823 cu in displacement and a Tier IV emission standard level.
How much horsepower does the 9560RT have?
The 9560RT has 401.2 kW (538 hp) of engine power.
What fuel does the John Deere 9560RT use?
The John Deere 9560RT uses Diesel fuel.
What jobs is this Tractors best suited for?
The supplied specifications indicate a tracked tractor with substantial engine power, hydraulic output, rear hitch capacity, and rear selective control valves. They do not confirm specific job applications or recommended implements.
What is the expected lifespan of the 9560RT?
The supplied data does not provide an expected service life for the 9560RT. For a used machine, assess maintenance records, engine condition, track wear, hydraulic performance, transmission operation, and hitch function.
What should a buyer check when purchasing a used Tractors?
Check service records, engine operation, track condition, transmission shifting, hydraulic system performance, rear selective control valves, PTO operation, hitch lift function, cab glass condition, and signs of leaks or damage.
