John Deere 8760 Articulated 4WD Tractors
John Deere 8760
Average price
$39,400
5+
sold in last year
General overview
John Deere 8760 is a wheeled farm tractor designed for large-scale field work and other demanding agricultural tasks. It uses a diesel engine with 10.1 L (616 cu in) displacement and is rated at 300 kW (408 hp), giving it the output class associated with high-capacity tractor applications. The 24-speed partial power shift transmission supports varied operating speeds in the field.
The model’s PTO output and hydraulic system are central to its work range. It is rated at 256 kW (348 hp) PTO power and reaches a maximum PTO power of 277 kW (377 hp). A closed-center pressure compensated hydraulic system with a pump rated output of 169.6 L/min (44.8 gpm) and a rear hitch category of Cat-III support mounted implements and other heavy-duty farm equipment.
Year
1989, 1990, 1991, 1992, 1993
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
2,600 mm
~102.4 in
3,200 mm
~126 in
6,830 mm
~268.9 in
14,558 kg
~32,094.9 lb
Tire or Track Type
Wheels
Engine Power
300 hp
Additional specifications
Emission standard level
Tier III
Engine type
Diesel
Displacement
616.4 cu(in)
Tires front
20.8R-38
Maximum PTO power
276.95 hp
Rated PTO power
256 hp
Speeds
1,000-2,100 RPM
Transmission type
24-speed partial power shift
Rear hitch category (SAE designation)
Cat-III
Fuel tank
832.7 L
Hydraulic system type
Closed-center pressure compensated
Pump rated output
169.6 L/min
Available flow at a single rear SCV
126 L/min
Tires rear
20.8R-38
John Deere 8760 Articulated 4WD Tractors Listings
$33,900
300 hp
Wheels
Diesel
10015 hours
Athens, United States
$44,900
300 hp
Wheels
Tier III
6999 hours
Holland, United States
Compare John Deere 8760 Articulated 4WD Tractor to other articulated 4wd tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 8760 Articulated 4WD Tractor
300 hp
14558 kg
6830 mm × 2600 mm × 3200 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 8760?
No confirmed market price is supplied for the John Deere 8760. Check current listings and compare the tractor’s condition, location, and configuration.
What are the key advantages of the John Deere 8760?
Listed strengths include 223.7 kW (300 hp) of engine power, a 24-speed partial power shift transmission, closed-center pressure compensated hydraulics, and a pump rated at 169.6 L/min (44.8 gpm). It also has a 832.7 L (220 US gal) fuel tank and Cat-III rear hitch.
What type of engine does the 8760 use?
The John Deere 8760 uses a diesel engine with 616.4 cu in displacement.
How much horsepower does the 8760 have?
The John Deere 8760 is listed with 223.7 kW (300 hp) of engine power. Maximum PTO power is 206.5 kW (277 hp), and rated PTO power is 190.9 kW (256 hp).
What fuel does the John Deere 8760 use?
The John Deere 8760 uses diesel fuel.
What jobs is this Tractors best suited for?
The supplied specifications indicate substantial engine and PTO power, Cat-III rear hitch compatibility, and high hydraulic flow. These features can be relevant when evaluating it for demanding farm work requiring PTO-driven or hydraulically operated implements. Specific job suitability depends on the implement, operating conditions, and tractor configuration.
What is the expected lifespan of the 8760?
The supplied data does not confirm an expected service life for the John Deere 8760. For a used tractor, assess maintenance records, engine condition, transmission operation, hydraulic performance, tires, and signs of leaks or wear.
What should a buyer check when purchasing a used Tractors?
Check service records, engine starting and operation, the 24-speed partial power shift transmission, hydraulic functions and rear SCVs, PTO operation, hitch condition, tire wear, leaks, and overall structural condition. Confirm that the tractor’s configuration and available hydraulic flow match the intended implements.
