John Deere 870 Compact Utility Tractors
John Deere 870
5+
sold in last yearGeneral overview
The John Deere 870 is a wheeled farm tractor built in the United States for general agricultural work. Powered by a diesel engine rated at 21 kW (28 hp), it is intended for routine field and implement tasks that require a modest power class and PTO capability.
Key operating features include a 9F/2R collar shift transmission, a rear PTO with live (two-stage clutch) operation at 540 rpm, and a Category 1 rear 3-point hitch with position control. Hydraulic support comes from an open center system with a pump rated output of 30 L/min (7.9 gpm), two rear selective control valves, and a maximum lift capacity behind lift points of 852 kg (1,880 lb). A solid front axle and power steering round out the tractor’s basic layout.
Year
1991
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
Weight
3,120 mm
~122.8 in
1,300 mm
~51.2 in
1,490 mm
~58.7 in
1,140 kg
~2,513.3 lb
Tire or Track Type
wheels
Engine Power
28 hp
Additional specifications
Engine type
diesel
Displacement
1 cu(m)
Maximum PTO power
25 hp
Rated PTO power
25 hp
Transmission type
9F/2R collar shift
Maximum lift capacity behind lift points
852 kg
Fuel tank
32 L
Hydraulic system type
open center
Pump rated output
30 L/min
Number of rear selective control valves
2
Sensing type
position control
Hitch type
1
Rear PTO
live (two-stage clutch)
Front Axle
solid
Rear 3-Point Hitch
position control
Guidance Ready
none
Additional Options
power steering
PTO speed
540
John Deere 870 Compact Utility Tractors Listings
Looking for John Deere 870 Compact Utility Tractors?
See similar listingsCompare John Deere 870 Compact Utility Tractor to other compact utility tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 870 Compact Utility Tractor
wheels
1140 kg
3120 mm × 1490 mm × 1300 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 870?
No confirmed market price is supplied for the John Deere 870. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere 870?
Listed features include a diesel engine, 20.9 kW (28 hp) engine power, 18.6 kW (25 hp) PTO power, live rear PTO, Category 1 hitch, open-center hydraulics, two rear selective control valves, and an available power-steering option.
What type of engine does the 870 use?
The John Deere 870 uses a diesel engine.
How much horsepower does the 870 have?
The John Deere 870 has 20.9 kW (28 hp) of engine power. Its rated and maximum PTO power are 18.6 kW (25 hp).
What fuel does the John Deere 870 use?
The John Deere 870 uses diesel fuel. Its fuel tank capacity is 32 L (8.5 US gal).
What jobs is this Tractors best suited for?
The supplied specifications do not confirm particular jobs or applications. Buyers can assess suitability based on its 20.9 kW (28 hp) engine, Category 1 rear hitch, 852 kg (1,878 lb) lift capacity, PTO, and hydraulic equipment requirements.
What is the expected lifespan of the 870?
No expected service-life figure is supplied for the John Deere 870. For a used tractor, inspect engine condition, transmission operation, PTO and hitch function, hydraulic performance, tires, and maintenance records.
What should a buyer check when purchasing a used Tractors?
Check the diesel engine, 9F/2R collar-shift transmission, live rear PTO, clutch operation, rear hitch lift, open-center hydraulic system, selective control valves, steering, tires, leaks, and maintenance records. Confirm that the fuel system and all controls operate properly.
