John Deere 8630 Articulated 4WD Tractors
John Deere 8630
Average price
$12,500
5+
sold in last year
General overview
John Deere 8630 is a farm tractor produced in the United States from 1975 to 1978. It was built for heavy-duty field work and drawbar applications, with a 202 kW (275 hp) diesel engine and a 10 L displacement. Its articulated 4WD axle with equal-size wheels supports operation in demanding agricultural conditions.
The tractor uses a 16-speed partial powershift / Syncro-Range style manual transmission and is configured with a rear PTO independent, 1000 rpm. Power take-off output is rated at 165 kW (225 hp), and the hydraulic system is a closed-center constant pressure design with a pump rated output of 125 L/min (33 gpm). A Category 3 hitch and a maximum lift capacity behind lift points of 5,897 kg (13,000 lb) further define its implement-handling capability.
Year
1975, 1976, 1977, 1978
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
Weight
5,670 mm
~223.2 in
3,410 mm
~134.3 in
3,171 mm
~124.8 in
10,948 kg
~24,136.2 lb
Tire or Track Type
wheels
Engine Power
275 hp
Additional specifications
Engine type
diesel
Displacement
10 cu(m)
Maximum PTO power
225 hp
Rated PTO power
225 hp
Transmission type
16-speed partial powershift / Syncro-Range style manual
Maximum lift capacity behind lift points
5,897 kg
Fuel tank
590 L
Hydraulic system type
closed-center constant pressure
Pump rated output
125 L/min
Number of rear selective control valves
2
Hitch type
3
Rear PTO
independent, 1,000 rpm
Front Axle
Articulated 4WD axle, equal-size wheels
Rear 3-Point Hitch
optional
Additional Options
Optional rear PTO (1,000 rpm); optional rear 3-point hitch; 2 rear SCVs
Tire type
Agricultural R-1 bias ply
PTO speed
["1,000"]
Tire Size
18.4-34
John Deere 8630 Articulated 4WD Tractors Listings
Compare John Deere 8630 Articulated 4WD Tractor to other articulated 4wd tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 8630 Articulated 4WD Tractor
wheels
10948 kg
5670 mm × 3171 mm × 3410 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 8630?
No confirmed market price is supplied. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere 8630?
Listed features include a 205.1 kW (275 hp) diesel engine, articulated 4WD axle with equal-size wheels, closed-center constant-pressure hydraulics, and a 125 L/min (33 gpm) pump. It also has 2 rear SCVs and available rear PTO and 3-point hitch equipment.
What type of engine does the 8630 use?
The 8630 uses a diesel engine.
How much horsepower does the 8630 have?
Engine power is 205.1 kW (275 hp). Rated and maximum PTO power are 167.8 kW (225 hp).
What fuel does the John Deere 8630 use?
The John Deere 8630 uses diesel fuel. Its fuel tank capacity is 590 L (155.9 US gal).
What jobs is this Tractors best suited for?
The supplied specifications do not confirm particular jobs. Its articulated 4WD axle, 205.1 kW (275 hp) diesel engine, hydraulic system, rear SCVs, and optional hitch and PTO indicate equipment features to assess against the implements and work required.
What is the expected lifespan of the 8630?
No expected service-life figure is supplied. For a used tractor, inspect engine condition, transmission operation, hydraulic performance, articulation components, tires, PTO operation, and maintenance records.
What should a buyer check when purchasing a used Tractors?
Check engine starting and operation, transmission shifting, hydraulic performance, articulation and axle condition, tire wear, fuel-system leaks, and the operation of the rear PTO and 3-point hitch if fitted. Review maintenance records and confirm the installed configuration, including rear SCVs.
