John Deere 8530 Row Crop Tractors
John Deere 8530
5+
sold in last yearGeneral overview
John Deere 8530 is a wheeled tractor designed for field and farm work, combining a diesel engine with 330 kW (449 hp) and a 9 L (548 cu in) displacement. It is intended for high-horsepower agricultural tasks that require sustained drawbar and PTO output.
The model uses a John Deere Infinitely Variable Transmission (IVT) and meets Tier 3 emissions. PTO output is listed at 312.7 kW (425 hp) maximum and 302.4 kW (411 hp) rated, while the closed center pressure-flow compensating PFC hydraulic system includes a pump rated output of 120 L/min (31.7 gpm). Rear hitch specification is Cat-IVN/III, with a maximum lift capacity behind lift points of 8,312 kg (18,320 lb), supporting heavy mounted implements and hydraulic control needs.
Year
2006, 2007, 2008, 2009
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
2,480 mm
~97.6 in
3,120 mm
~122.8 in
5,560 mm
~218.9 in
12,156 kg
~26,799.4 lb
Tire or Track Type
Wheels
Engine Power
330 hp
Additional specifications
Emission standard level
Tier 3
Engine type
Diesel
Displacement
548 cu(in)
Tires front
540/65R34
Maximum PTO power
312.73 hp
Rated PTO power
302.39 hp
Speeds
900-2,200 RPM
Transmission type
John Deere Infinitely Variable Transmission (IVT)
Rear hitch category (SAE designation)
Cat-IVN/III
Maximum lift capacity behind lift points
8,312 kg
Fuel tank
681.3 L
Hydraulic system type
Closed center pressure-flow compensating PFC
Pump rated output
120 L/min
Number of rear selective control valves
3 to 5
Tires rear
650/85R38
Transmission Speeds
John Deere 8530 Row Crop Tractors Listings
Looking for John Deere 8530 Row Crop Tractors?
See similar listingsCompare John Deere 8530 Row Crop Tractor to other row crop tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 8530 Row Crop Tractor
330 hp
12156 kg
5560 mm × 2480 mm × 3120 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 8530?
No confirmed market price is supplied. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere 8530?
Listed features include a Diesel engine rated at 246.1 kW (330 hp), John Deere Infinitely Variable Transmission (IVT), closed center pressure-flow compensating PFC hydraulics, and maximum lift capacity behind lift points of 8,312 kg (18,325 lb).
What type of engine does the 8530 use?
The 8530 uses a Diesel engine with 548 cu in displacement and Tier 3 emissions standard level.
How much horsepower does the 8530 have?
Engine Power is 246.1 kW (330 hp). Maximum PTO power is 233.2 kW (312.7 hp), and Rated PTO power is 225.5 kW (302.4 hp).
What fuel does the John Deere 8530 use?
The John Deere 8530 uses Diesel fuel. Its fuel tank capacity is 681.3 L (180 US gal).
What jobs is this Tractors best suited for?
The supplied specifications do not confirm particular jobs. Its listed capabilities include wheels, a rear hitch category of Cat-IVN/III, up to 8,312 kg (18,325 lb) lift capacity behind lift points, and 3 to 5 rear selective control valves.
What is the expected lifespan of the 8530?
The supplied data does not provide an expected lifespan. For a used tractor, inspect maintenance records, engine condition, transmission operation, hydraulic performance, hitch function, tires, and signs of leaks or wear.
What should a buyer check when purchasing a used Tractors?
Check maintenance records, Diesel engine condition, John Deere Infinitely Variable Transmission (IVT) operation, hydraulic system performance, rear hitch lift function, selective control valves, tire condition, fuel-system leaks, and general wear. Confirm that the configuration matches the intended work.
