John Deere 8430 Row Crop Tractors
John Deere 8430
Average price
$119,900
5+
sold in last year
General overview
John Deere 8430 is a wheeled farm tractor designed for demanding field operations. It is powered by a diesel engine rated at 305 kW (415 hp) with 9 L (548 cu in) displacement, giving it the output needed for heavy tillage and other large-tractor work.
This model uses a 16-speed full power shift transmission and carries a Tier 3 emissions level. PTO output is rated at 273.4 kW (372 hp) and reaches 289.3 kW (393 hp) maximum, while the rear hitch is Cat III with a maximum lift capacity behind lift points of 7,847 kg (17,300 lb). A closed center PFC hydraulic system and 120 L/min (31.7 gpm) pump output support rear implements.
Year
2006, 2007, 2008, 2009
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
2,480 mm
~97.6 in
3,120 mm
~122.8 in
5,560 mm
~218.9 in
11,770 kg
~25,948.4 lb
Tire or Track Type
Wheels
Engine Power
305 hp
Additional specifications
Emission standard level
Tier 3
Engine type
Diesel
Displacement
548 cu(in)
Tires front
540/65R34
Maximum PTO power
289.26 hp
Rated PTO power
273.44 hp
Speeds
900-2,200 RPM
Transmission type
16-speed full power shift
Rear hitch category (SAE designation)
Cat III
Maximum lift capacity behind lift points
7,847 kg
Fuel tank
681.3 L
Hydraulic system type
Closed center PFC
Pump rated output
120 L/min
Number of rear selective control valves
3 to 5
Tires rear
650/85R38
John Deere 8430 Row Crop Tractors Listings
$119,900
305 hp
Wheels
Tier 3
7135 hours
Effingham, United States
Compare John Deere 8430 Row Crop Tractor to other row crop tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 8430 Row Crop Tractor
305 hp
11770 kg
5560 mm × 2480 mm × 3120 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 8430?
No confirmed market price is supplied for the John Deere 8430. Check current listings and compare machine condition, location, hours, maintenance records, and configuration.
What are the key advantages of the John Deere 8430?
Listed strengths include 227.4 kW (305 hp) engine power, a 16-speed full power shift transmission, closed center PFC hydraulics, 120 L/min (31.7 gpm) pump output, and up to 7,847 kg (17,300 lb) rear lift capacity.
What type of engine does the 8430 use?
The John Deere 8430 uses a diesel engine with 548 cu in displacement and a Tier 3 emission standard level.
How much horsepower does the 8430 have?
The John Deere 8430 has 227.4 kW (305 hp) of engine power. Maximum PTO power is 215.7 kW (289.3 hp), while rated PTO power is 203.9 kW (273.4 hp).
What fuel does the John Deere 8430 use?
The John Deere 8430 uses diesel fuel. Its fuel tank capacity is 681.3 L (180 US gal).
What jobs is this Tractors best suited for?
The supplied data does not specify particular jobs. Buyers can match its 227.4 kW (305 hp) engine power, Cat III rear hitch, PTO output, hydraulic capacity, and wheeled configuration to the implements and tasks they plan to run.
What is the expected lifespan of the 8430?
The supplied data does not confirm an expected service life for the 8430. Condition depends on maintenance, operating history, load, and inspection findings, including the engine, transmission, hydraulics, PTO, hitch, and tires.
What should a buyer check when purchasing a used Tractors?
Inspect maintenance records, engine operation, transmission shifting, hydraulic function, PTO engagement, rear hitch operation, tire condition, leaks, and signs of structural damage. Confirm that the available rear selective control valves and other configuration details suit the intended implements.
