John Deere 8130 Row Crop Tractors
John Deere 8130
5+
sold in last yearGeneral overview
John Deere 8130 is a wheeled farm tractor produced in the United States from 2006 to 2007. It is powered by a diesel engine with a displacement of 9 L and an engine output of 165 kW (225 hp), placing it in the higher-power range for agricultural tractor work. The model is intended for field operations that require traction, PTO power, and implement handling.
Key operating features include a 16-speed full power shift transmission, an independent rear PTO with 540 and 1000 speeds, and a rear 3-Point Hitch rated III/IIIN with a 3N hitch type. PTO output is rated at 132 kW (180 hp) and reaches a maximum of 153 kW (208 hp). The hydraulic system is a closed center PFC design with a pump rated output of 120 L/min (31.7 gpm), and maximum lift capacity behind the lift points is 5,624 kg (12,400 lb).
Year
2006, 2007
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Weight
5,560 mm
~218.9 in
3,120 mm
~122.8 in
9,876 kg
~21,772.9 lb
Tire or Track Type
wheels
Engine Power
225 hp
Additional specifications
Engine type
diesel
Displacement
9 cu(m)
Maximum PTO power
208 hp
Rated PTO power
180 hp
Transmission type
16-speed full power shift
Maximum lift capacity behind lift points
5,624 kg
Fuel tank
681 L
Hydraulic system type
closed center PFC
Pump rated output
120 L/min
Hitch type
3N
Rear PTO
independent
Rear 3-Point Hitch
III/IIIN
Tire type
agricultural
PTO speed
540, 1,000
Tire Size
Front: 11.00-24; Rear: 480/80R46
John Deere 8130 Row Crop Tractors Listings
Looking for John Deere 8130 Row Crop Tractors?
See similar listingsCompare John Deere 8130 Row Crop Tractor to other row crop tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 8130?
No confirmed market price is supplied. Check current listings and compare the tractor’s condition, location, hours, maintenance history, and configuration.
What are the key advantages of the John Deere 8130?
Listed features include 167.8 kW (225 hp) engine power, a 16-speed full power shift transmission, independent rear PTO with 540 and 1000 speeds, closed center PFC hydraulics, and a rear hitch lift capacity of 5,624 kg (12,399 lb).
What type of engine does the 8130 use?
The John Deere 8130 uses a diesel engine.
How much horsepower does the 8130 have?
The 8130 has engine power of 167.8 kW (225 hp). Its rated PTO power is 134.2 kW (180 hp), with maximum PTO power of 155.1 kW (208 hp).
What fuel does the John Deere 8130 use?
The John Deere 8130 uses diesel fuel. Its listed fuel tank capacity is 681 L (179.9 US gal).
What jobs is this Tractors best suited for?
The supplied specifications do not identify specific jobs. Its agricultural tires, rear 3-point hitch, independent rear PTO, hydraulic system, and 16-speed full power shift transmission support use with compatible farm implements.
What is the expected lifespan of the 8130?
The supplied data does not confirm an expected service life. For a used tractor, condition depends on maintenance history, operating hours, engine and transmission condition, hydraulic performance, and overall wear.
What should a buyer check when purchasing a used Tractors?
Check the engine, transmission, PTO operation, hydraulic system, rear hitch, tires, fuel system, and maintenance records. Test the 16-speed full power shift transmission, verify PTO operation at 540 and 1000, and inspect for leaks, wear, and damage.
