John Deere 6430 Premium Row Crop Tractors
John Deere 6430 Premium
5+
sold in last yearGeneral overview
John Deere 6430 Premium is a wheeled tractor produced in the United States for general farm work and field operations that use mounted or PTO-driven implements. It is powered by a diesel engine with 4.5 L (276 cu in) displacement and an output of 85 kW (115 hp), placing it in a mid-power tractor class for agricultural tasks.
The model is listed with Tier III emissions compliance and transmission options that include Fully synchronized; SyncShuttle™ power shuttle; PowrReverser™; optional IVT. Drive configuration is 4×2 (2WD), with optional 4×4 MFWD with planetary final drives and hydrostatic power steering. PTO output is rated at 70 kW (95 hp) and maximum PTO power at 86 kW (116.7 hp), while the rear hitch is Category II with a maximum lift capacity behind lift points of 2,313 kg (5,100 lb). A closed-center hydraulic system with a pump rated output of 109.8 L/min (29 gpm) and 2 – 4 rear selective control valves supports implement operation.
Year
2007, 2008, 2009, 2010, 2011, 2012
Country of manufacturing
United States
General specifications
Dimensions
Length
Weight
Width
Height
4,290 mm
~168.9 in
4,566 kg
~10,066.3 lb
2,320 mm
~91.3 in
2,740 mm
~107.9 in
Tire or Track Type
Wheels
Engine Power
115 hp
Additional specifications
Emission standard level
Tier III
Engine type
Diesel
Displacement
276 cu(in)
Tires front
Front: 10.00-16;
Maximum PTO power
116.7 hp
Rated PTO power
95 hp
Speeds
540@ 2,412
Transmission type
Fully synchronized; SyncShuttleâ„¢ power shuttle; PowrReverserâ„¢; optional IVT
Rear hitch category (SAE designation)
Category II
Maximum lift capacity behind lift points
2,313 kg
Fuel tank
181.7 L
Hydraulic system type
Closed-center
Pump rated output
109.8 L/min
Number of rear selective control valves
2 – 4
Sensing type
Lower-link draft sensing
Tires rear
Rear: 16.9R30
Front Axle
4×2 (2WD); optional 4×4 MFWD with planetary final drives; hydrostatic power steering
John Deere 6430 Premium Row Crop Tractors Listings
Looking for John Deere 6430 Premium Row Crop Tractors?
See similar listingsCompare John Deere 6430 Premium Row Crop Tractor to other row crop tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 6430 Premium Row Crop Tractor
115 hp
4566 kg
4290 mm × 2320 mm × 2740 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 6430 Premium?
No confirmed market price is supplied. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere 6430 Premium?
Supplied features include a diesel engine rated at 85.8 kW (115 hp), closed-center hydraulics with 109.8 L/min (29 gpm) pump output, Category II rear hitch, and optional 4×4 MFWD. Transmission choices include SyncShuttle™ power shuttle, PowrReverser™, and optional IVT.
What type of engine does the 6430 Premium use?
The 6430 Premium uses a diesel engine with 276 cu in displacement and Tier III emissions standard level.
How much horsepower does the 6430 Premium have?
Engine power is 85.8 kW (115 hp). Maximum PTO power is 87 kW (116.7 hp), while rated PTO power is 70.8 kW (95 hp).
What fuel does the John Deere 6430 Premium use?
The John Deere 6430 Premium uses diesel fuel. Its fuel tank capacity is 181.7 L (48 US gal).
What jobs is this Tractors best suited for?
The supplied specifications support use with rear-mounted implements requiring a Category II hitch, draft sensing, rear selective control valves, and hydraulic flow. Specific jobs or application suitability are not confirmed by the supplied data.
What is the expected lifespan of the 6430 Premium?
The supplied data does not confirm an expected service life. For a used tractor, inspect maintenance records, engine condition, transmission operation, hydraulics, PTO, hitch, steering, and tire condition.
What should a buyer check when purchasing a used Tractors?
Check maintenance records; diesel-engine condition; transmission and shuttle operation; hydraulic pump and rear selective control valves; PTO operation; rear hitch lift and draft sensing; steering; axle configuration; tire condition; leaks; and overall wear. Confirm the installed transmission and whether it has 4×2 (2WD) or optional 4×4 MFWD.
