John Deere 6430 Row Crop Tractors
John Deere 6430
5+
sold in last yearGeneral overview
John Deere 6430 is a wheeled farm tractor produced from 2007 to 2012. It is powered by a diesel engine with 4 L (244 cu in) displacement and an output of 120 kW (163 hp), placing it in the medium-power class for general field and farm transport work.
The model offers a 12/16/24-speed transmission, maximum PTO power of 99 kW (135 hp), and 540/1000 rpm PTO speeds for operating compatible implements. A Cat-2 rear hitch with a maximum lift capacity behind lift points of 2,920 kg (6,440 lb) supports mounted equipment, while the closed-center load-sensing hydraulic system and 64 L/min (16.9 gpm) pump rated output provide implement control.
Year
2007, 2008, 2009, 2010, 2011, 2012
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
2,320 mm
~91.3 in
2,750 mm
~108.3 in
4,360 mm
~171.7 in
4,536 kg
~10,000.2 lb
Tire or Track Type
Wheels
Engine Power
120 hp
Additional specifications
Emission standard level
Tier III/Stage IIIA
Engine type
Diesel
Displacement
274 cu(in)
Maximum PTO power
99 hp
Speeds
540/1,000 rpm
Transmission type
12/16/24-speed
Rear hitch category (SAE designation)
Cat-2
Maximum lift capacity behind lift points
2,920 kg
Fuel tank
165 L
Cab glass area
5.8 sq(m)
Hydraulic system type
Closed-center load-sensing system
Pump rated output
64 L/min
SCV control
Mechanical
Transmission Speeds
Tires
18.4x38
John Deere 6430 Row Crop Tractors Listings
Looking for John Deere 6430 Row Crop Tractors?
See similar listingsCompare John Deere 6430 Row Crop Tractor to other row crop tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 6430 Row Crop Tractor
120 hp
4536 kg
4360 mm × 2320 mm × 2750 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 6430?
No confirmed market price is supplied for the John Deere 6430. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the John Deere 6430?
Listed strengths include 89.5 kW (120 hp) engine power, 73.8 kW (99 hp) maximum PTO power, a closed-center load-sensing hydraulic system, 64 L/min (16.9 gpm) pump output, and 2,920 kg (6,437 lb) maximum rear lift capacity.
What type of engine does the 6430 use?
The 6430 uses a diesel engine with 274 cu in displacement and a Tier III/Stage IIIA emission standard level.
How much horsepower does the 6430 have?
The John Deere 6430 has engine power of 89.5 kW (120 hp). Its maximum PTO power is 73.8 kW (99 hp).
What fuel does the John Deere 6430 use?
The John Deere 6430 uses diesel fuel. Its fuel tank capacity is 165 L (43.6 US gal).
What jobs is this Tractors best suited for?
The supplied specifications do not confirm specific jobs. Its PTO, Cat-2 rear hitch, hydraulic system, and rear lift capacity indicate compatibility with implements that match those specifications.
What is the expected lifespan of the 6430?
The supplied data does not provide an expected service-life estimate for the 6430. Assess maintenance records, operating condition, engine performance, hydraulics, transmission, PTO, hitch, and signs of wear when evaluating a machine.
What should a buyer check when purchasing a used Tractors?
Check service records, engine operation, transmission shifting, hydraulic performance, PTO operation, rear hitch function, tire condition, leaks, cab condition, and overall wear. Confirm that the configuration and implements are compatible with the tractor’s specifications.
