John Deere 624G Wheel Loaders
John Deere 624G
Average price
$34,500
5+
sold in last year
General overview
The John Deere 624G is a wheel loader for construction loading and material-handling work. It uses a John Deere 6068T 6-cylinder, 6 L engine rated at 110 kW (150 hp), with net power of 107 kW (145 hp), and has an operating weight of 12,634 kg (27,850 lb).
Its heaped bucket capacity is 2 m³ (2.6 cu yd), and forward travel speed reaches 37 km/h (23 mph). Key geometry includes a wheelbase of 2,997 mm (9 ft 10 in), a width of 2,515 mm (8 ft 3 in), a hinge pin at maximum height of 3,807 mm (12 ft 6 in), a reach at maximum dump height of 3,250 mm (10 ft 8 in), and a dump angle at maximum height of 45°.
Year
1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
7,438 mm
~292.8 in
3,288 mm
~129.4 in
2,515 mm
~99 in
Engine Power
150 hp
Operating Weight
12,634 kg
Bucket Capacity
2 cu(m)
Bucket Capacity - Heaped
2 cu(m)
Additional specifications
Displacement
6 cu(m)
Fuel tank
248 L
Cooling system
25 L
Height to top of cab
3,288 mm
Wheelbase
2,997 mm
Number of Cylinders
6
Ground clearance with standard tires
434 mm
Battery Voltage
12
Width
2,515 mm
System Relief Pressure
19,310 kPa
Travel Speed Forward
37 km/h
Engine Model
John Deere 6,068T
Engine Oil
19 L
Maximum Reach at Ground Level
5,588 mm
Power - Net
145 hp
Net Power (ISO 9249)
145 hp
General Purpose
2 cu(m)
Light Material
2 cu(m)
Hydraulic Cycle Time - Lower, Float
5 s
Hydraulic Cycle Time - Lift
5 s
Hydraulic Cycle Time - Dump
1 s
Overall Length - With Bucket
7,438 mm
Reach at Maximum Dump Height
3,250 mm
Load Over Height
3,280 mm
Hinge Pin at Maximum Height
3,807 mm
Overall Length - With Forks
7,950 mm
Fork Height at Maximum Reach
3,353 mm
Width - Over Bucket
3,080 mm
Tire Gauge
3,080 mm
Steering Angle
26 deg
Dump Angle at Maximum Height
45 deg
Hydraulic System
102 L
Angle of Departure
26 deg
Rated Operating Capacity
5,800 kg
John Deere 624G Wheel Loaders Listings
Compare John Deere 624G Wheel Loader to other wheel loaders
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 624G?
No confirmed market price is supplied for the John Deere 624G. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere 624G?
Listed specifications include 108.1 kW (145 hp) net power, a 2 m³ (2.62 cu yd) heaped bucket capacity, 37 km/h (23 mph) forward travel speed, and a 12,634 kg (27,853 lb) operating weight.
What type of engine does the 624G use?
The 624G uses a John Deere 6068T engine with 6 cylinders.
How much horsepower does the 624G have?
The 624G has 150 hp engine power and 145 hp net power, including Net Power (ISO 9249).
What fuel does the John Deere 624G use?
The supplied specifications do not confirm the fuel type. They list a fuel tank capacity of 248 L (65.5 US gal).
What jobs is this Wheel Loaders best suited for?
The supplied data does not specify recommended job types. It lists a General Purpose bucket capacity of 2 m³ (2.62 cu yd), which may be relevant when evaluating the machine for loading and material-handling work.
What is the expected lifespan of the 624G?
No expected service-life figure is supplied for the 624G. Actual lifespan depends on maintenance history, operating conditions, hours, and the condition of major components.
What should a buyer check when purchasing a used Wheel Loaders?
Inspect maintenance records, engine operation, hydraulic leaks and cycle function, steering, brakes, tires, bucket or forks, articulation joints, cab controls, and structural wear. Confirm operating hours and test the machine under load where possible.
