John Deere 6125R Row Crop Tractors
John Deere 6125R
5+
sold in last yearGeneral overview
John Deere 6125R is a wheeled farm tractor for general field operations and other routine farm tasks. Built in the United States from 2012 to 2014, it is powered by a diesel engine rated at 92 kW (125 hp) with 4.5 L (276 cu in) displacement and meets Stage IIIb emissions requirements.
Powertrain options include partial power shift and infinitely variable (IVT) transmission types. The model is listed with 87 kW (117.9 hp) maximum PTO power and 74 kW (101 hp) rated PTO power. Its load-sensing, pressure-flow compensated hydraulic system provides 113.6 L/min (30 gpm) pump output and 99.9 L/min (26.4 gpm) available at a single rear SCV. Rear implement equipment includes a Category 2/3N hitch, electronic lower-link draft sensing, and 2,937 kg (6,470 lb) maximum lift capacity behind the lift points.
Year
2012, 2013, 2014
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
2,550 mm
~100.4 in
2,790 mm
~109.8 in
4,540 mm
~178.7 in
5,910 kg
~13,029.3 lb
Tire or Track Type
Wheels
Engine Power
125 hp
Additional specifications
Emission standard level
Stage IIIb
Engine type
Diesel
Displacement
276 cu(in)
Tires front
Front: 12.4R24;
Maximum PTO power
117.9 hp
Rated PTO power
101 hp
Speeds
540@ 2,409
Transmission type
16-speed partial power shift; 24-speed partial power shift; infinitely variable (IVT)
Rear hitch category (SAE designation)
Category 2/3N
Maximum lift capacity behind lift points
2,937 kg
Fuel tank
219.5 L
Hydraulic system type
Load-sensing, pressure-flow compensated
Pump rated output
113.6 L/min
Available flow at a single rear SCV
99.9 L/min
Number of rear selective control valves
3
Sensing type
Lower-link draft sensing
Tires rear
Rear: 16.9R30 (4WD)
Front Axle
Triple-Link Suspension front axle
Rear 3-Point Hitch
Electronic lower-link draft sensing
John Deere 6125R Row Crop Tractors Listings
Looking for John Deere 6125R Row Crop Tractors?
See similar listingsCompare John Deere 6125R Row Crop Tractor to other row crop tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 6125R Row Crop Tractor
125 hp
5910 kg
4540 mm × 2550 mm × 2790 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 6125R?
No confirmed market price is supplied. Check current listings and compare the tractor’s condition, location, and configuration.
What are the key advantages of the John Deere 6125R?
Listed features include 93.2 kW (125 hp) engine power, load-sensing pressure-flow-compensated hydraulics, 3 rear selective control valves, and a maximum rear lift capacity of 2,937 kg (6,475 lb). Transmission options include partial power shift and IVT.
What type of engine does the 6125R use?
The 6125R uses a Diesel engine with 276 cu in displacement and a Stage IIIb emission standard level.
How much horsepower does the 6125R have?
Engine power is 93.2 kW (125 hp). Maximum PTO power is 87.9 kW (117.9 hp), and rated PTO power is 75.3 kW (101 hp).
What fuel does the John Deere 6125R use?
The John Deere 6125R uses Diesel fuel. Its fuel tank capacity is 219.5 L (58 US gal).
What jobs is this Tractors best suited for?
The supplied specifications do not confirm specific job applications. Assess the required PTO power, hydraulic flow, rear-hitch capacity, tire setup, and transmission type against the intended work.
What is the expected lifespan of the 6125R?
The supplied data does not confirm an expected service life. For a used tractor, maintenance history, operating hours, engine condition, hydraulics, transmission operation, and hitch performance are practical factors to inspect.
What should a buyer check when purchasing a used Tractors?
Check engine operation, transmission shifting, hydraulic flow, rear SCVs, PTO function, three-point hitch lift, tire condition, front axle suspension, leaks, and maintenance records. Confirm that the tractor’s transmission, tire, and hydraulic configuration match the intended work.
