John Deere 6120R Row Crop Tractors
John Deere 6120R
5+
sold in last yearGeneral overview
John Deere 6120R is a wheeled tractor designed for farm operations that require a mid-range power class and flexible implement handling. It is powered by a 4.5 L diesel engine rated at 88 kW (120 hp) and meets Tier 4 Final emission standards. The model was produced in the United States from 2016 to 2022.
The 6120R is equipped with an Infinitely variable transmission (IVT), MFWD, and an independent rear PTO, supporting a range of PTO-driven and draft applications. Key work features include a Category 2 hitch, electronic lower-link draft sensing, a closed-center, pressure-and-flow compensated hydraulic system, a pump rated output of 114 L/min (30.1 gpm), a maximum lift capacity behind lift points of 2,531 kg (5,580 lb), and Guidance Ready capability.
Year
2016, 2017, 2018, 2019, 2020, 2021, 2022
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
Weight
4,533 mm
~178.5 in
2,886 mm
~113.6 in
1,680 mm
~66.1 in
6,100 kg
~13,448.2 lb
Tire or Track Type
wheels
Engine Power
120 hp
Additional specifications
Emission standard level
Tier 4 Final
Engine type
diesel
Displacement
4,5 cu(m)
Rated PTO power
94 hp
Transmission type
Infinitely variable transmission (IVT)
Maximum lift capacity behind lift points
2,531 kg
Fuel tank
194,9 L
Cab glass area
6,11 sq(m)
Hydraulic system type
closed-center, pressure-and-flow compensated
Pump rated output
114 L/min
Available flow at a single rear SCV
100 L/min
Number of rear selective control valves
2
SCV control
Mechanical
Sensing type
electronic lower-link draft sensing
Hitch type
2
Rear PTO
independent
Front Axle
MFWD
Rear 3-Point Hitch
Category 2 hitch
Guidance Ready
guidance_ready
Tire type
agricultural
PTO speed
540, 540E, 1,000
Tire Size
Front: 10.00-16, Rear: 18.4R34
John Deere 6120R Row Crop Tractors Listings
Looking for John Deere 6120R Row Crop Tractors?
See similar listingsCompare John Deere 6120R Row Crop Tractor to other row crop tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 6120R Row Crop Tractor
wheels
6100 kg
4533 mm × 1680 mm × 2886 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 6120R?
No confirmed market price is supplied for the John Deere 6120R. Check current listings and compare the tractor’s condition, location, and configuration.
What are the key advantages of the John Deere 6120R?
Listed features include a 89.5 kW (120 hp) diesel engine, Infinitely variable transmission (IVT), MFWD front axle, independent rear PTO, Category 2 hitch, closed-center pressure-and-flow compensated hydraulics, and guidance readiness.
What type of engine does the 6120R use?
The 6120R uses a diesel engine with a Tier 4 Final emission standard level.
How much horsepower does the 6120R have?
The 6120R has an engine power rating of 89.5 kW (120 hp).
What fuel does the John Deere 6120R use?
The John Deere 6120R uses diesel fuel.
What jobs is this Tractors best suited for?
The supplied data does not specify intended jobs. Its independent rear PTO, Category 2 hitch, hydraulic system, rear selective control valves, and MFWD configuration support use with compatible agricultural implements.
What is the expected lifespan of the 6120R?
The supplied data does not provide an expected lifespan for the 6120R. Service history, operating conditions, maintenance, and inspection of major systems are more useful indicators of a specific tractor’s condition.
What should a buyer check when purchasing a used Tractors?
Check service records, engine operation, transmission performance, PTO operation, hydraulics, hitch lift, rear selective control valves, tire condition, cab condition, and signs of leaks or damage. Confirm that the installed configuration matches the intended implements.
