John Deere 544GTC Wheel Loaders
John Deere 544GTC
Average price
$23,900
5+
sold in last yearGeneral overview
John Deere 544GTC is a wheel loader used for loading, material handling, and other construction-site tasks. It is powered by an 88 kW (120 hp) engine, has an operating weight of 11,167 kg (24,620 lb), and offers a heaped bucket capacity of 3 m³ (3.9 cu yd).
The model uses a 5.9L 6-cyl diesel engine and is rated at 85 kW (115 hp) net power under ISO 9249 with Tier 1 emissions. It also lists a travel speed of 38 km/h (23.6 mph), a turning radius over bucket of 5,660 mm (18 ft 7 in), and a width of 2,462 mm (8 ft 1 in). With a height to top of cab of 3,327 mm (10 ft 11 in), a wheelbase of 2,895 mm (9 ft 6 in), overall length with bucket of 7,098 mm (23 ft 3 in), and 40° articulation and steering angle, it is suited to maneuvering around loading areas.
Year
1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
mm
~ in
3,327 mm
~131 in
mm
~ in
Engine Power
120 hp
Operating Weight
11,167 kg
Bucket Capacity
2.1 cu(m)
Bucket Capacity - Heaped
3 cu(m)
Additional specifications
Emission standard level
Tier 1
Displacement
5 cu(m)
Fuel tank
218 L
Cooling system
24 L
Height to top of cab
3,327 mm
Wheelbase
2,895 mm
Number of Cylinders
6
Ground clearance with standard tires
406 mm
Battery Voltage
24
Width
2,462 mm
System Relief Pressure
18,960 kPa
Travel Speed Forward
38 km/h
Engine Model
5.9L 6-cyl diesel
Battery Capacity
950
Engine Oil
19 L
Maximum Reach at Ground Level
1,950 mm
Power - Net
115 hp
Net Power (ISO 9249)
115 hp
General Purpose
2 cu(m)
Light Material
4 cu(m)
3rd Auxiliary Flow
189 L/min
Hydraulic Cycle Time - Lower, Float
2 s
Hydraulic Cycle Time - Lift
5 s
Hydraulic Cycle Time - Dump
1 s
Overall Length - With Bucket
7,098 mm
Reach at Maximum Dump Height
1,060 mm
Load Over Height
2,819 mm
Hinge Pin at Maximum Height
3,700 mm
Fork Height at Maximum Reach
3,700 mm
Turning Radius - Over Bucket
5,660 mm
Width - Over Bucket
2,990 mm
Tire Gauge
2,170 mm
Articulation Angle
40 deg
Steering Angle
40 deg
Dump Angle at Maximum Height
22 deg
Hydraulic System
76 L
Turning Radius - Inside Tire
4,800 mm
Angle of Departure
22 deg
Rated Operating Capacity
3,442 kg
John Deere 544GTC Wheel Loaders Listings
Looking for John Deere 544GTC Wheel Loaders?
See similar listingsCompare John Deere 544GTC Wheel Loader to other wheel loaders
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 544GTC?
No confirmed market price is supplied for the John Deere 544GTC. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the John Deere 544GTC?
Listed specifications include 89.5 kW (120 hp) engine power, an operating weight of 11,167 kg (24,619 lb), 3 m³ (3.92 cu yd) heaped bucket capacity, 38 km/h (23.6 mph) forward travel speed, and a 40° articulation angle.
What type of engine does the 544GTC use?
The 544GTC uses a 5.9L 6-cyl diesel engine with 6 cylinders. Its listed emission standard level is Tier 1.
How much horsepower does the 544GTC have?
The 544GTC has listed engine power of 89.5 kW (120 hp). Net power is listed as 85.8 kW (115 hp), including Net Power (ISO 9249).
What fuel does the John Deere 544GTC use?
The John Deere 544GTC uses diesel fuel, according to its listed 5.9L 6-cyl diesel engine. The fuel tank capacity is 218 L (57.6 US gal).
What jobs is this Wheel Loaders best suited for?
The supplied specifications do not identify specific intended jobs for this Wheel Loaders. Review the bucket capacity options, operating weight, hydraulic performance, and site requirements to determine whether it matches the planned work.
What is the expected lifespan of the 544GTC?
The supplied data does not confirm an expected service life for the 544GTC. For a used machine, assess maintenance records, engine condition, hydraulic operation, articulation wear, tires, and structural condition.
What should a buyer check when purchasing a used Wheel Loaders?
Check service records, engine starting and operation, hydraulic leaks and cycle performance, articulation and steering play, tire condition, bucket and linkage wear, brakes, cab controls, and signs of frame damage or repairs. Confirm that the machine’s configuration matches the intended work.
