John Deere 5130M Utility Tractors
John Deere 5130M
Average price
$107,500
5+
sold in last year
General overview
John Deere 5130M is a tractor designed for farm operations that use mounted and PTO-driven implements. It is powered by a diesel engine with 130 kW (177 hp) and meets Final Tier 4 emission standards.
The model uses a PowerQuad PLUS 16F/16R transmission and offers PTO speeds of 540 at 2100 rpm, 540E at 1645 rpm, and 1000 at 2100 rpm, with rated PTO power of 115 kW (156 hp) and maximum PTO power of 133 kW (181 hp). A Category 2 rear hitch, maximum lift capacity behind lift points of 3,164 kg (6,980 lb), and an open center hydraulic system with 97 L/min (25.6 gpm) pump output support a range of implement work.
Year
2023, 2024, 2025
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
1,880 mm
~74 in
2,640 mm
~103.9 in
4,081 mm
~160.7 in
4,175 kg
~9,204.3 lb
Tire or Track Type
Wheels
Engine Power
130 kW
Additional specifications
Emission standard level
Final Tier 4
Engine type
Diesel
Displacement
4,500 cu(cm)
Tires front
Standard Wheels
Maximum PTO power
133.9 hp
Rated PTO power
115 hp
Speeds
1,000 at 2,200 rpm
Transmission type
PowrQuadâ„¢ PLUS 16F/16R
Rear hitch category (SAE designation)
Category 2; convertible to 1
Base machine weight
3,964 kg
Maximum lift capacity behind lift points
3,164 kg
Fuel tank
165.4 L
Cab glass area
sq(m)
Hydraulic system type
Open center
Pump rated output
97 L/min
Available flow at a single rear SCV
73 L/min
Number of rear selective control valves
2 to 3
SCV control
Mechanical
Sensing type
Lower link
John Deere 5130M Utility Tractors Listings
$107,500
97 L/min
4500 cu(cm)
Wheels
170 hours
Anchorage, United States
Compare John Deere 5130M Utility Tractor to other utility tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 5130M Utility Tractor
130 kW
4175 kg
4081 mm × 1880 mm × 2640 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 5130M?
No confirmed market price is supplied for the John Deere 5130M. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the John Deere 5130M?
Listed features include 130 kW (174.3 hp) engine power, a PowrQuadâ„¢ PLUS 16F/16R transmission, 99.8 kW (133.9 hp) maximum PTO power, 3,164 kg (6,975 lb) lift capacity, and a 97 L/min (25.6 gpm) open-center hydraulic pump.
What type of engine does the 5130M use?
The 5130M uses a Diesel engine with 4,500 cc displacement and a Final Tier 4 emission standard level.
How much horsepower does the 5130M have?
The 5130M has 130 kW (174.3 hp) of engine power. Its maximum PTO power is 99.8 kW (133.9 hp), and rated PTO power is 85.8 kW (115 hp).
What fuel does the John Deere 5130M use?
The John Deere 5130M uses Diesel fuel. Its fuel tank capacity is 165.4 L (43.7 US gal).
What jobs is this Tractors best suited for?
The supplied specifications do not confirm specific intended jobs. Buyers can assess implement needs against its Category 2; convertible to 1 rear hitch, PTO power, open-center hydraulics, rear SCVs, and maximum lift capacity.
What is the expected lifespan of the 5130M?
The supplied data does not provide an expected service life for the 5130M. For a used machine, inspect maintenance records, engine condition, transmission operation, hydraulics, PTO, hitch function, tires, and signs of leaks or damage.
What should a buyer check when purchasing a used Tractors?
Check maintenance records, engine starting and operation, PowrQuadâ„¢ PLUS 16F/16R shifting, PTO function, hydraulic pump and rear SCVs, hitch lift operation, tire condition, fuel system condition, leaks, and visible damage. Confirm the configuration matches the required implements.
