John Deere 5105M Utility Tractors
John Deere 5105M
5+
sold in last yearGeneral overview
John Deere 5105M is a wheeled tractor for farm operations that use mounted or PTO-driven implements. It is powered by a diesel engine rated at 74 kW (100 hp) with a displacement of 4.5 L (276 cu in), and it meets Tier IV emissions requirements. This places the model in a mid-power class suited to general agricultural work.
The tractor is equipped with mechanical MFWD, planetary final drives, and hydrostatic power steering. PTO output is rated at 62 kW (85 hp), with maximum PTO power of 67 kW (90.7 hp) and 540@ 2400 speed. A Category II rear hitch, open-center hydraulic system, pump rated output of 85.2 L/min (22.5 gpm), and available flow at a single rear SCV of 60.2 L/min (15.9 gpm) support implement operation.
Year
2009, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
1,760 mm
~69.3 in
2,296 mm
~90.4 in
4,089 mm
~161 in
3,200 kg
~7,054.8 lb
Tire or Track Type
Wheels
Engine Power
100 hp
Additional specifications
Emission standard level
Tier IV
Engine type
Diesel
Displacement
276 cu(in)
Tires front
Front: 12.4-24;
Maximum PTO power
90.65 hp
Rated PTO power
85 hp
Speeds
540@ 2,400
Rear hitch category (SAE designation)
Category II
Fuel tank
113.6 L
Hydraulic system type
Open-center
Pump rated output
85.2 L/min
Available flow at a single rear SCV
60.2 L/min
Number of rear selective control valves
2 or 3
Sensing type
Top-link draft sensing
Tires rear
Rear: 18.4-30
Front Axle
Mechanical MFWD; planetary final drives; hydrostatic power steering
John Deere 5105M Utility Tractors Listings
Looking for John Deere 5105M Utility Tractors?
See similar listingsCompare John Deere 5105M Utility Tractor to other utility tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 5105M Utility Tractor
100 hp
3200 kg
4089 mm × 1760 mm × 2296 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 5105M?
No confirmed market price is supplied. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere 5105M?
Listed features include a diesel engine with 74.6 kW (100 hp), wheels, Tier IV emissions, Category II rear hitch, open-center hydraulics, and 2 or 3 rear selective control valves. The front axle has Mechanical MFWD, planetary final drives, and hydrostatic power steering.
What type of engine does the 5105M use?
The 5105M uses a diesel engine with 276 cu in displacement.
How much horsepower does the 5105M have?
Engine power is 74.6 kW (100 hp). Rated PTO power is 63.4 kW (85 hp), and maximum PTO power is 67.6 kW (90.7 hp).
What fuel does the John Deere 5105M use?
The John Deere 5105M uses diesel fuel.
What jobs is this Tractors best suited for?
The supplied specifications do not confirm particular job applications. Its Category II rear hitch, PTO, rear selective control valves, and hydraulic system support use with compatible implements, but suitability depends on the implement and operating requirements.
What is the expected lifespan of the 5105M?
The supplied data does not provide an expected service-life estimate. Inspect maintenance records, engine condition, hydraulic performance, PTO operation, tires, steering, and front axle condition when evaluating a tractor.
What should a buyer check when purchasing a used Tractors?
Check maintenance records, diesel engine operation, hydraulic output, rear selective control valves, PTO function, hitch operation, tire condition, steering, and the Mechanical MFWD front axle. Confirm the tractor's configuration, hours, and overall condition before purchase.
