John Deere 5100M Utility Tractors
John Deere 5100M
5+
sold in last yearGeneral overview
John Deere 5100M is a wheel tractor produced for general farm operations that rely on mounted implements and PTO-driven equipment. It is powered by a diesel engine rated at 100 kW (136 hp), with Tier III emissions compliance and 4.5 L (276 cu in) displacement, giving it a straightforward power profile for agricultural work in field and yard settings.
The model uses a two-speed power shift transmission and is equipped with a Category 2 rear hitch. PTO output is 85 kW (116 hp), and the rear lift system is rated at 2,957 kg (6,520 lb) behind the lift points. Its open center hydraulic system provides 93.9 L/min (24.8 gpm) pump output, with lower-link sensing and mechanical or electrohydraulic SCV control for attached equipment.
Year
2009, 2010, 2011, 2012, 2013, 2022
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
1,829 mm
~72 in
2,489 mm
~98 in
3,607 mm
~142 in
3,700 kg
~8,157.1 lb
Tire or Track Type
Wheels
Engine Power
100 hp
Additional specifications
Emission standard level
Tier III
Engine type
Diesel
Displacement
276 cu(in)
Tires front
13.6R24
Rated PTO power
85 hp
Speeds
1,500-2,200 RPM
Transmission type
Two-speed power shift
Rear hitch category (SAE designation)
2
Maximum lift capacity behind lift points
2,957 kg
Fuel tank
111.9 L
Hydraulic system type
Open center
Pump rated output
93.9 L/min
Available flow at a single rear SCV
70 L/min
Number of rear selective control valves
2-3
SCV control
Mechanical or electrohydraulic
Sensing type
Lower link
Tires rear
16.9R34
John Deere 5100M Utility Tractors Listings
Looking for John Deere 5100M Utility Tractors?
See similar listingsCompare John Deere 5100M Utility Tractor to other utility tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 5100M Utility Tractor
100 hp
3700 kg
3607 mm × 1829 mm × 2489 mm
Add model
Add model
4.0
Rating
Based on ratings and reviews from verified buyers.
Overall rating
1 reviews
5
4
3
2
1
Performance & Productivity
4.0
Reliability & Durability
3.0
Comfort & Ergonomics
4.0
Safety
5.0
Technology & Features
5.0
Vernon Kowalczyk
We've run ours for four seasons and it's been a genuine workhorse. Auto-steer with RTK keeps us inside an inch pass to pass on the high-speed disk. It holds rpm steady when the 57-foot vertical-till tool loads up.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 5100M?
No confirmed market price is supplied. Check current listings and compare condition, location, and configuration.
What are the key advantages of the John Deere 5100M?
Supplied specifications include 74.6 kW (100 hp) engine power, 63.4 kW (85 hp) rated PTO power, a two-speed power shift transmission, Category 2 rear hitch, open-center hydraulics, and 2-3 rear selective control valves.
What type of engine does the 5100M use?
The 5100M uses a diesel engine with 276 cu in displacement and a Tier III emission standard level.
How much horsepower does the 5100M have?
The 5100M has 74.6 kW (100 hp) engine power. Its rated PTO power is 63.4 kW (85 hp).
What fuel does the John Deere 5100M use?
The John Deere 5100M uses diesel fuel. Its fuel tank capacity is 111.9 L (29.6 US gal).
What jobs is this Tractors best suited for?
The supplied data does not confirm specific jobs. Its listed Category 2 rear hitch, rear lift capacity, PTO power, hydraulic system, and rear SCVs indicate compatibility with appropriately matched rear-mounted and hydraulic implements.
What is the expected lifespan of the 5100M?
The supplied data does not provide an expected service-life estimate. For a used tractor, assess maintenance records, engine condition, transmission operation, hydraulic performance, PTO function, hitch operation, tires, and leaks.
What should a buyer check when purchasing a used Tractors?
Check maintenance records, diesel-engine starting and operation, two-speed power shift function, hydraulic output and rear SCVs, PTO operation, Category 2 hitch lift, tire condition, fuel-system leaks, and overall wear. Confirm the tractor's configuration matches the intended implements.
