John Deere 5090E Utility Tractors
John Deere 5090E
Average price
$65,000
5+
sold in last year
General overview
John Deere 5090E is a wheeled tractor for general farm work, including field operations and implement handling. It is powered by a diesel engine with 66 kW (90 hp) and 4.5 L (275 cu in) of displacement, placing it in a mid-power class suited to routine agricultural tasks.
The model is offered with 12-speed power shuttle; 24-speed power shuttle transmission options and rated PTO power of 55 kW (75 hp). The rear Category II hitch supports implements with a maximum lift capacity behind lift points of 1,457 kg (3,210 lb), while the open-center hydraulic system provides a pump rated output of 85.2 L/min (22.5 gpm) and available flow at a single rear SCV of 60.2 L/min (15.9 gpm). The front axle uses inboard planetary final drives and hydrostatic power steering.
Year
2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
2,160 mm
~85 in
2,600 mm
~102.4 in
4,040 mm
~159.1 in
3,696 kg
~8,148.3 lb
Tire or Track Type
Wheels
Engine Power
90 hp
Additional specifications
Engine type
Diesel
Displacement
275 cu(in)
Tires front
Front: 12.4-24;
Maximum PTO power
75 hp
Rated PTO power
75 hp
Speeds
540@2,400
Transmission type
12-speed power shuttle; 24-speed power shuttle
Rear hitch category (SAE designation)
Category II
Maximum lift capacity behind lift points
1,457 kg
Fuel tank
112.4 L
Hydraulic system type
Open-center
Pump rated output
85.2 L/min
Available flow at a single rear SCV
60.2 L/min
Number of rear selective control valves
2 or 3
Tires rear
Rear: 18.4-30
Front Axle
Inboard planetary final drives; hydrostatic power steering
Rear 3-Point Hitch
Top-link draft sensing
John Deere 5090E Utility Tractors Listings
$62,500
Power Reverser
90 hp
Wheels
101 hours
Poplarville, United States
$67,500
90 hp
Wheels
Diesel
191 hours
Rolling Fork, United States
Compare John Deere 5090E Utility Tractor to other utility tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 5090E Utility Tractor
90 hp
3696 kg
4040 mm × 2160 mm × 2600 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 5090E?
No confirmed market price is supplied. Check current listings and compare the tractor’s condition, location, and configuration.
What are the key advantages of the John Deere 5090E?
Supplied specifications include 67.1 kW (90 hp) engine power, 55.9 kW (75 hp) PTO power, open-center hydraulics, and a maximum lift capacity of 1,457 kg (3,212 lb) behind lift points. It also offers 2 or 3 rear selective control valves.
What type of engine does the 5090E use?
The 5090E uses a diesel engine with 275 cu in displacement.
How much horsepower does the 5090E have?
The 5090E has 67.1 kW (90 hp) of engine power. Maximum and rated PTO power are 55.9 kW (75 hp).
What fuel does the John Deere 5090E use?
The John Deere 5090E uses diesel fuel. Its fuel tank capacity is 112.4 L (29.7 US gal).
What jobs is this Tractors best suited for?
The supplied data does not confirm specific jobs. Its listed features include Category II rear hitch, top-link draft sensing, 55.9 kW (75 hp) PTO power, and rear hydraulic SCVs, which can support use with compatible implements.
What is the expected lifespan of the 5090E?
The supplied data does not confirm an expected lifespan. For a used tractor, inspect maintenance records, engine condition, hydraulics, PTO operation, hitch function, tires, and transmission performance.
What should a buyer check when purchasing a used Tractors?
Check maintenance records, engine starting and operation, transmission shifting, hydraulic output and rear SCVs, PTO function, hitch lift, steering, axle condition, tire wear, leaks, and signs of damage or repairs. Confirm that the installed configuration matches the intended implements.
