John Deere 5075GN Wheeled Tractors (Narrow)
John Deere 5075GN
5+
sold in last yearGeneral overview
John Deere 5075GN is a wheeled farm tractor designed for general agricultural work that requires PTO and rear hitch implement support. It is powered by a diesel engine rated at 75 kW (102 hp) with a displacement of 3 L (183 cu in), and it meets Tier 4 Final / Stage IV emissions requirements.
The model uses a 24F/12R PowrReverserâ„¢ transmission and delivers 57.6 kW (78 hp) of rated PTO power, with maximum PTO power of 61 kW (83 hp) at 540 RPM. Rear implement capability includes a Category 2 hitch, maximum lift capacity behind lift points of 1,630 kg (3,590 lb), an open-center hydraulic system, pump rated output of 97 L/min (25.6 gpm), two rear selective control valves, electrohydraulic SCV control, and top-link sensing.
Year
2021, 2022, 2023, 2024
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
1,260 mm
~49.6 in
1,710 mm
~67.3 in
3,760 mm
~148 in
2,660 kg
~5,864.3 lb
Tire or Track Type
Wheels
Engine Power
75 hp
Additional specifications
Emission standard level
Tier 4 Final / Stage IV
Engine type
Diesel
Displacement
183 cu(in)
Tires front
7.50-16 R1
Maximum PTO power
61 hp
Rated PTO power
57.6 hp
Speeds
540 RPM
Transmission type
24F/12R PowrReverserâ„¢
Rear hitch category (SAE designation)
2
Maximum lift capacity behind lift points
1,630 kg
Fuel tank
73 L
Hydraulic system type
Open-center
Pump rated output
97 L/min
Available flow at a single rear SCV
64 L/min
Number of rear selective control valves
2
SCV control
Electrohydraulic
Sensing type
Top-link sensing
Tires rear
12.4-28 R1
John Deere 5075GN Wheeled Tractors (Narrow) Listings
Looking for John Deere 5075GN Wheeled Tractors (Narrow)?
See similar listingsCompare John Deere 5075GN Wheeled Tractors (Narrow) to other wheeled tractors (narrow)
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 5075GN Wheeled Tractors (Narrow)
75 hp
2660 kg
3760 mm × 1260 mm × 1710 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 5075GN?
No confirmed market price is supplied. Check current listings and compare the tractor’s condition, location, configuration, and included attachments.
What are the key advantages of the John Deere 5075GN?
Listed features include a 55.9 kW (75 hp) diesel engine, 24F/12R PowrReverserâ„¢ transmission, open-center hydraulics, two electrohydraulic rear SCVs, and Category 2 rear hitch capacity of 1,630 kg (3,594 lb).
What type of engine does the 5075GN use?
The 5075GN uses a diesel engine with 183 cu in displacement and Tier 4 Final / Stage IV emissions compliance.
How much horsepower does the 5075GN have?
Engine power is 55.9 kW (75 hp). Maximum PTO power is 45.5 kW (61 hp), while rated PTO power is 43 kW (57.6 hp).
What fuel does the John Deere 5075GN use?
The John Deere 5075GN uses diesel fuel. Its fuel tank capacity is 73 L (19.3 US gal).
What jobs is this Tractors best suited for?
The supplied specifications do not confirm specific intended jobs. Assess implement compatibility using the Category 2 rear hitch, 1,630 kg (3,594 lb) lift capacity, 540 RPM PTO, and available hydraulic flow.
What is the expected lifespan of the 5075GN?
No expected service-life figure is supplied. Lifespan depends on maintenance, operating conditions, workload, and inspection of the engine, transmission, hydraulics, PTO, and hitch components.
What should a buyer check when purchasing a used Tractors?
Check maintenance records, engine operation, fluid condition, transmission shifting, PTO operation, hydraulic response, rear SCVs, hitch function, tire condition, leaks, and signs of structural damage or excessive wear. Confirm the tractor’s configuration matches the intended implements.
