John Deere 5055E Utility Tractors
John Deere 5055E
Average price
$19,500
5+
sold in last year
General overview
John Deere 5055E is a wheeled tractor designed for general farm operations and implement work. It is powered by a 59 kW (80 hp) diesel engine with 2.9 L (176 cu in) displacement and meets Tier 4 Final / Stage IV emission standards. The model was produced from 2010 to 2017.
Key working features include a 9F/3R SyncShuttleâ„¢ transmission, a maximum PTO power of 53 kW (72 hp), and a rated PTO power of 41 kW (56 hp) at 540 RPM. It uses an open-center hydraulic system with a pump rated output of 68.6 L/min (18.1 gpm), one rear SCV with 43.1 L/min (11.4 gpm) available flow, and a rear hitch category of Cat-2 with mechanical SCV control and top-link sensing.
Year
2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
1,450 mm
~57.1 in
1,360 mm
~53.5 in
3,500 mm
~137.8 in
2,299 kg
~5,068.4 lb
Tire or Track Type
Wheels
Engine Power
59 hp
Additional specifications
Emission standard level
Tier 4 Final / Stage IV
Engine type
Diesel
Displacement
2,900 cu(cm)
Tires front
7.5-16 R1
Maximum PTO power
53 hp
Rated PTO power
41 hp
Speeds
540 RPM
Transmission type
9F/3R SyncShuttleâ„¢
Rear hitch category (SAE designation)
Cat-2
Maximum lift capacity behind lift points
1.448 kg
Fuel tank
72.5 L
Hydraulic system type
Open-center hydraulic system
Pump rated output
68.6 L/min
Available flow at a single rear SCV
43.1 L/min
Number of rear selective control valves
1
SCV control
Mechanical
Sensing type
Top-link sensing
Tires rear
13.6-28 R1
John Deere 5055E Utility Tractors Listings
$11,500
59 hp
Wheels
Diesel
2091 hours
Lapeer, United States
Compare John Deere 5055E Utility Tractor to other utility tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 5055E Utility Tractor
59 hp
2299 kg
3500 mm × 1450 mm × 1360 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 5055E?
No confirmed market price is supplied. Check current listings and compare the tractor’s condition, location, and configuration.
What are the key advantages of the John Deere 5055E?
The supplied specifications list a diesel engine rated at 44 kW (59 hp), 9F/3R SyncShuttleâ„¢ transmission, open-center hydraulic system, and one mechanically controlled rear SCV. It also has Cat-2 rear hitch compatibility and 540 RPM PTO speed.
What type of engine does the 5055E use?
The John Deere 5055E uses a diesel engine with 2,900 cc displacement and Tier 4 Final / Stage IV emissions level.
How much horsepower does the 5055E have?
Engine power is rated at 44 kW (59 hp). Maximum PTO power is 39.5 kW (53 hp), while rated PTO power is 30.6 kW (41 hp).
What fuel does the John Deere 5055E use?
The John Deere 5055E uses diesel fuel. Its fuel tank capacity is 72.5 L (19.2 US gal).
What jobs is this Tractors best suited for?
The supplied data does not confirm specific intended jobs. Its listed features include 540 RPM PTO speed, Cat-2 rear hitch, open-center hydraulics, and one rear SCV, so suitability depends on the implements and work requirements.
What is the expected lifespan of the 5055E?
The supplied data does not provide an expected service life. For a used tractor, inspect maintenance records, engine condition, transmission operation, hydraulics, PTO, hitch, tires, and signs of leaks or damage.
What should a buyer check when purchasing a used Tractors?
Check maintenance records and inspect the diesel engine, 9F/3R SyncShuttleâ„¢ transmission, hydraulics, PTO, rear hitch, SCV operation, tires, fuel system, and overall condition. Test controls for smooth operation and look for leaks, wear, or damage.
