John Deere 4710 Compact Utility Tractors
John Deere 4710
5+
sold in last yearGeneral overview
John Deere 4710 is a wheeled tractor produced in the United States from 2002 to 2004. It is built for general farm work in field and chore settings and is powered by a 34 kW (46 hp) diesel engine with 2 L displacement.
The model was offered with either a 12F/12R PowrReverser gear or 3-range hydrostatic (HST) transmission, and it uses an MFWD front axle with power steering. A Category 1 rear 3-point hitch, position control, and a lift capacity of 998 kg (2,200 lb) support implement work, while the independent 540 rpm rear PTO provides 28 kW (38 hp), with a maximum PTO power of 29 kW (40 hp). Its open center hydraulic system delivers 47 L/min (12.4 gpm) through three rear selective control valves.
Year
2002, 2003, 2004
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
Weight
3,104 mm
~122.2 in
2,370 mm
~93.3 in
1,750 mm
~68.9 in
1,564 kg
~3,448 lb
Tire or Track Type
wheels
Engine Power
46 hp
Additional specifications
Engine type
diesel
Displacement
2 cu(m)
Maximum PTO power
40 hp
Rated PTO power
38 hp
Transmission type
12F/12R PowrReverser gear or 3-range hydrostatic (HST)
Maximum lift capacity behind lift points
998 kg
Fuel tank
47 L
Hydraulic system type
Open center
Pump rated output
47 L/min
Number of rear selective control valves
3
SCV control
Mechanical spool valves (lever/joystick control)
Sensing type
Position control
Hitch type
1
Rear PTO
Independent 540 rpm
Front Axle
MFWD front axle, power steering
Rear 3-Point Hitch
Yes
Guidance Ready
none
Loader
Compatible with John Deere 430 and 460 front loaders
Additional Options
Transmission type, MFWD, rear/mid PTO, R1/R4 tires, rear SCV count, loaders, ROPS/cab
Tire type
Agricultural (R1) or Industrial (R4)
PTO speed
540
Tire Size
Front: 8.00-16 / Rear: 13.6-28; optional Front: 10-16.5 / Rear: 17.5L-24
John Deere 4710 Compact Utility Tractors Listings
Looking for John Deere 4710 Compact Utility Tractors?
See similar listingsCompare John Deere 4710 Compact Utility Tractor to other compact utility tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 4710 Compact Utility Tractor
wheels
1564 kg
3104 mm × 1750 mm × 2370 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 4710?
No confirmed market price is supplied. Check current listings and compare condition, location, hours, and installed configuration.
What are the key advantages of the John Deere 4710?
Key listed features include 34.3 kW (46 hp) diesel power, MFWD front axle with power steering, a Category 1 rear hitch, and up to 998 kg (2,200 lb) lift capacity. It also offers PTO, hydraulic, tire, transmission, loader, ROPS, and cab configuration options.
What type of engine does the 4710 use?
The 4710 uses a diesel engine.
How much horsepower does the 4710 have?
The John Deere 4710 has 34.3 kW (46 hp) of engine power. Rated PTO power is 28.3 kW (38 hp), with maximum PTO power of 29.8 kW (40 hp).
What fuel does the John Deere 4710 use?
The John Deere 4710 uses diesel fuel. Its fuel tank capacity is 47 L (12.4 US gal).
What jobs is this Tractors best suited for?
The supplied specifications indicate a tractor with a Category 1 rear hitch, independent rear PTO, open-center hydraulics, rear selective control valves, and compatibility with John Deere 430 and 460 front loaders. Specific best-use applications are not confirmed by the supplied data.
What is the expected lifespan of the 4710?
The supplied data does not provide an expected service-life estimate. For a used tractor, inspect engine operation, transmission response, PTO and hydraulic function, hitch lift, steering, tires, and maintenance records.
What should a buyer check when purchasing a used Tractors?
Check engine operation, fuel-system condition, transmission and shuttle or HST response, MFWD and steering function, PTO operation, hydraulics and rear SCVs, Category 1 hitch lift, tire condition, loader mounts if fitted, and maintenance records. Confirm the installed options match the intended use.
