John Deere 324J Wheel Loaders
John Deere 324J
5+
sold in last yearGeneral overview
Year
2012
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
Weight
5,760 mm
~226.8 in
2,790 mm
~109.8 in
2,200 mm
~86.6 in
6,080 kg
~13,404.1 lb
Additional specifications
Engine Power
73 hp
Emission standard level
Stage IIIB
Cold Cranking Amp
1,700
Operating Weight
6,080 kg
Bucket Capacity
1.1 cu(m)
Engine Model
5,030T
Power - Net
73 hp
Net Power (ISO 9249)
73 hp
General Purpose
1.1 cu(m)
Light Material
1.6 cu(m)
Hydraulic Cycle Time - Lower, Float
4.5 s
Bucket Capacity - Heaped
1.1 cu(m)
Hydraulic Cycle Time - Lift
5.3 s
Hydraulic Cycle Time - Dump
1.6 s
Overall Length - With Bucket
5,760 mm
Reach at Maximum Dump Height
884 mm
Dig Depth
69 mm
Maximum Dump Height
2,670 mm
Hinge Pin at Maximum Height
3,350 mm
Overall Length - With Forks
6,140 mm
Fork Depth Above Ground
-36 mm
Fork Height at Maximum Reach
1,360 mm
Maximum Fork Height
3,190 mm
Fork Reach at Maximum Height
569 mm
Width - Over Bucket
2,200 mm
Tire Gauge
1,661 mm
Articulation Angle
28 deg
Steering Angle
26 deg
Dump Angle at Maximum Height
42 deg
Cab Height
2,790 mm
Ground Clearance
386 mm
Dimensions machine width
2,075 mm
Dimensions maximum reach
1,520 mm
Dimensions reach ground level
749 mm
Dimensions wheelbase
2,300 mm
Electrical system voltage
12
Engine number of cylinders
5
Hydraulic main relief
18,961 kPa
Transmission travel speed
29.9 km/h
