John Deere 320 Skid Steer / CTL
John Deere 320
Average price
$18,690
5+
sold in last year
General overview
The John Deere 320 is a skid steer loader for construction sites where compact size and lift performance matter. Powered by a 4-cylinder 4 L engine rated at 49 kW (66 hp), it has an operating weight of 2,920 kg (6,440 lb), a rated operating capacity of 953 kg (2,100 lb), and a tipping load of 2,722 kg (6,000 lb).
A hydrostatic drive with single speed supports straightforward control, and maximum travel speed is 10 km/h (6.2 mph). Other defining specifications include a dump height of 2,515 mm (8 ft 3 in) and a width without bucket of 1,524 mm (5 ft), which help define its working range and footprint. It is built for repetitive loading and maneuvering in confined spaces around buildings and other obstacles.
Year
2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
3,195 mm
~125.8 in
1,937 mm
~76.3 in
1,753 mm
~69 in
Engine Power
66 hp
Operating Weight
2,550 kg
Rated Operating Capacity
953 kg
Dump Height
2,515 mm
Bucket volume
440 cu(m)
Max. speed
10 km/h
Additional specifications
Emission standard level
Tier 4 / Stage IV (for later models post-2,014; earlier 2,004 models: Tier 3)
Displacement
4 cu(m)
Speeds
Single speed
Fuel tank
60 L
Number of batteries
1
Wheelbase
1,067 mm
Battery Voltage
12
Net Power (ISO 9249)
62 hp
Manufacturer and Model
John Deere 4,024T (alt: Yanmar 4TNV88 in some configs)
Alternator Rating
95
Pump flow loader
72 L/min
2 Speed High
11 km/h
Tractive Effort
205 kN
System Pressure at Couplers
24,132 kPa
Hydraulic Horsepower Flow
62 hp
Length Without Bucket
3,162 mm
Length With Foundry Bucket
3,162 mm
Width Without Bucket
1,524 mm
Height to Top of ROPS
1,937 mm
Height to Hinge Pin
3,124 mm
Dump Height With Foundry Bucket
2,570 mm
Dump Reach With Foundry Bucket
762 mm
Dump Reach With Construction Bucket
800 mm
Ground Clearance
488 mm
Angle of Departure
25 deg
Front Turn Radius With Foundry Bucket
1,930 mm
Dump Angle (full lift height)
40 deg
Bucket Rollback (ground level)
35 deg
Tipping Load
2,722 kg
SAE Rated Operating Capacity With Counterweight
1,089 kg
Boom Breakout Force With Foundry Bucket
34 kg
Boom Breakout Force With Construction Bucket
36 kg
Bucket Breakout Force With Foundry Bucket
44 kg
Bucket Breakout Force With Construction Bucket
46 kg
Powertrain Type
Hydrostatic drive
Operating Weight - Rear
2,920 kg
Standard features
12x16.5 10 PR SKS; Alt: Solid tires
Seed spacing
5 mm
Cylinders
4
John Deere 320 Skid Steer / CTL Listings
$18,690
66 hp
440 cu(m)
12
4845 hours
Rock Springs, United States
Compare John Deere 320 Skid Steer / CTL to other skid steer / ctl
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 320?
No confirmed market price is supplied. Check current listings and compare machine condition, location, operating hours, and configuration.
What are the key advantages of the John Deere 320?
Listed strengths include 49.2 kW (66 hp) engine power, a 953 kg (2,101 lb) rated operating capacity, hydrostatic drive, and 72 L/min (19 gpm) loader pump flow.
What type of engine does the 320 use?
The listed engine is a John Deere 4024T. Some configurations use a Yanmar 4TNV88. The engine has 4 cylinders.
How much horsepower does the 320 have?
Engine power is listed as 49.2 kW (66 hp). Net Power (ISO 9249) is 46.2 kW (62 hp).
What fuel does the John Deere 320 use?
The supplied data does not confirm the fuel type for the John Deere 320.
What jobs is this Skid Steer Loaders best suited for?
Its rated operating capacity, dump height, hydrostatic drive, and loader hydraulic flow indicate suitability for general loading, material handling, and work requiring compatible skid-steer attachments.
What is the expected lifespan of the 320?
The supplied data does not provide an expected service life. For a used machine, inspect maintenance records, engine condition, hydraulics, tires, controls, and structural wear.
What should a buyer check when purchasing a used Skid Steer Loaders?
Check maintenance records, engine starting and operation, hydraulic leaks and coupler pressure, tire condition, loader-arm and bucket wear, controls, ROPS condition, and any included attachments.
