John Deere 30G Compact & Mini (Tracked) Excavators
John Deere 30G
Average price
$35,000
5+
sold in last year
General overview
John Deere 30G is an excavator for construction and earthmoving work. It has an operating weight of 3,105 kg (6,850 lb) and engine power of 17 kW (23 hp). The model uses a Yanmar engine with 1 L displacement, and it was manufactured in the United States.
Its working dimensions include a width of 1,550 mm (5 ft 1 in), a track gauge of 1,250 mm (4 ft 1 in), and a tail swing radius of 775 mm (31 in). Maximum digging depth is 2,790 mm (9 ft 2 in), with maximum reach at ground level of 4,890 mm (16 ft 1 in), maximum cutting height of 4,620 mm (15 ft 2 in), and maximum loading height of 3,200 mm (10 ft 6 in). Travel speeds are 2 km/h (1.2 mph) low and 4 km/h (2.5 mph) high, and maximum rated flow is 76 L/min (20.1 gpm).
Year
2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
4,450 mm
~175.2 in
2,480 mm
~97.6 in
1,550 mm
~61 in
Engine Power
23 hp
Displacement
1 cu(m)
Fuel tank
42 L
Number of batteries
1
Number of Cylinders
3
Width
1,550 mm
Operating Weight
3,105 kg
Maximum Rated Flow
76 L/min
Hydraulic Pumps
cu(cm)
Hydraulic Capacity
43 L
Engine Model
Yanmar
Maximum Travel Speed - Low
2 km/h
Maximum Travel Speed - High
4 km/h
Hydraulic System - Including Tank
43 L
Shipping Height - Top of Cab
2,480 mm
Tail Swing Radius
775 mm
Track Gauge
1,250 mm
Maximum Digging Depth
2,790 mm
Boom working ranges
mm
Stick working ranges
mm
Maximum Reach at Ground Level
4,890 mm
Maximum Cutting Height
4,620 mm
Maximum Loading Height
3,200 mm
Stick length
1,170 mm
Net Power (ISO 9249)
23 hp
Additional specifications
Rated power
14.6 kW
Reference Bucket Capacity
0.08 cu(m)
Ground Pressure
28 kPa
John Deere 30G Compact & Mini (Tracked) Excavators Listings
$37,500
23 hp
3105 kg
Yanmar
261 hours
Rogers, United States
Compare John Deere 30G Compact & Mini (Tracked) Excavator to other compact & mini (tracked) excavators
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 30G Compact & Mini (Tracked) Excavator
23 hp
4450 mm × 1550 mm × 2480 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 30G?
No confirmed market price is supplied for the John Deere 30G. Check current listings and compare machine condition, location, hours, and configuration.
What are the key advantages of the John Deere 30G?
The supplied specifications show a compact 1,550 mm width, 3,105 kg operating weight, 2,790 mm maximum digging depth, and 4,890 mm maximum reach at ground level. It also has 17.2 kW (23 hp) net power and 76 L/min (20.1 gpm) maximum rated hydraulic flow.
What type of engine does the 30G use?
The John Deere 30G uses a Yanmar engine with 3 cylinders.
How much horsepower does the 30G have?
The John Deere 30G has 17.2 kW (23 hp) of engine power. Its net power under ISO 9249 is also listed as 17.2 kW (23 hp).
What fuel does the John Deere 30G use?
The supplied specifications do not confirm the fuel type for the John Deere 30G.
What jobs is this Excavators best suited for?
The supplied data does not specify intended applications. Its 1,550 mm width, 2,790 mm maximum digging depth, and 4,890 mm maximum reach at ground level may be relevant when assessing fit for work areas and excavation requirements.
What is the expected lifespan of the 30G?
No expected service-life figure is supplied for the John Deere 30G. Evaluate maintenance records, operating condition, hydraulic performance, engine condition, undercarriage wear, and signs of leaks when assessing a specific machine.
What should a buyer check when purchasing a used Excavators?
Check service records, engine starting and operation, hydraulic response, leaks, cylinder condition, boom and stick play, track and undercarriage wear, controls, safety equipment, and structural damage. Confirm the machine’s configuration and inspect it under operating conditions where possible.
