J&M 750 Single Auger
J&M 750
5+
sold in last yearGeneral overview
J&M 750 is a grain cart from J&M designed for moving harvested grain during field operations. It is specified with a power requirement of 110 kW (150 hp) and a PTO speed of 1,000 rpm, placing it in a tractor-operated class suited to high-volume crop transfer.
The model uses a WPT/PTO-driven planetary gearbox (1.75:1 ratio) with an optional hydraulic motor drive and requires 2 remote hydraulic circuits (one for auger raise/lower, one for spout rotation); 12-15 gpm flow at 2000 psi recommended. Material handling capacity is defined by a peak unloading rate of 14,096 L/min (3,723.8 gpm), a 457 mm (18 in) vertical auger, and a 406 mm (16 in) horizontal auger. Empty weight is 6,350 kg (14,000 lb), with hitch weight listed at 522 kg (1,150 lb) empty and 1,293 kg (2,850 lb) loaded.
Year
2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
3,658 mm
~144 in
4,420 mm
~174 in
3,658 mm
~144 in
Unloading rate
5,946.34 L/min
Grain Cart Capacity
26,400 L
Required Engine Power
111.86 kW
Grain Cart Loaded Tongue Weight
1,292.74 kg
Grain Cart Empty Tongue Weight
521.63 kg
Grain Cart Auger Diameter
0.46 m
Flighting Thickness
0.25 in
Hub Size/Spindle Diameter
10 Bolt hubs; 4-1/2 in spindle diameter
Hydraulic Remotes Required
3
Front/Rear Slopes
38° front / 40° rear
Hopper Length
3.89 m
Hopper Width
3.66 m
Auger Side Reach Max
4.88 m
Auger Side Reach Min
3.05 m
Grain Cart Overall Transport Length
6.96 m
Additional specifications
Peak unloading rate
14,096 L/min
Power requirement
150 hp
Capacity Heaped
26,500 cu(m)
Tractor hydraulics requirements
2 remote hydraulic circuits (one for auger raise/lower, one for spout rotation); 12-15 gpm flow at 2,000 psi recommended.
Total weight - empty
6,350 kg
Hitch weight - empty
522 kg
Hitch weight - loaded
1,293 kg
PSI capacity
207 kPa
Vertical auger
457 mm
Horizontal auger
406 mm
Gearbox
WPT/PTO-driven planetary gearbox (1.75:1 ratio); optional hydraulic motor drive.
Drive belts
5-rib QD belt drive (Gates Super HC or equivalent).
Drive sheaves
18 in drive sheave, 14 in driven sheave (cast iron, double-row bearings).
PTO speed
1,000
J&M 750 Single Auger Listings
Looking for J&M 750 Single Auger?
See similar listingsCompare J&M 750 Single Auger to other single auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a J&M 750?
No confirmed market price is supplied for the J&M 750. Check current listings and compare condition, location, and configuration.
What are the key advantages of the J&M 750?
Listed features include a 26,500 m³ (34,660.67 cu yd) heaped capacity, a peak unloading rate of 14,096 L/min (3,723.8 gpm), and PTO-driven unloading through a WPT planetary gearbox. An optional hydraulic motor drive is also listed.
What type of engine does the 750 use?
The supplied information does not identify an engine for the J&M 750. It lists a power requirement of 111.9 kW (150 hp) and a PTO speed of 1,000 rpm.
How much horsepower does the 750 have?
The J&M 750 has a listed power requirement of 111.9 kW (150 hp).
What fuel does the J&M 750 use?
The supplied information does not specify a fuel type. The J&M 750 is listed with a tractor power requirement and PTO-driven gearbox, rather than an onboard engine.
What jobs is this Grain carts best suited for?
As a grain cart, the J&M 750 is suited for handling and unloading grain where a tractor can supply 111.9 kW (150 hp), a 1,000 rpm PTO, and two remote hydraulic circuits. Its listed peak unloading rate is 14,096 L/min (3,723.8 gpm).
What is the expected lifespan of the 750?
The supplied information does not provide an expected service life for the J&M 750. Inspect the augers, gearbox, belt drive, hydraulic components, hitch, tires, and cart structure, and review maintenance history before purchase.
What should a buyer check when purchasing a used Grain carts?
Check the augers, WPT/PTO-driven planetary gearbox, 5-rib QD belt drive, drive sheaves, hydraulic circuits, spout rotation, hitch, tires, and cart structure. Verify PTO operation at 1,000 rpm and look for wear, leaks, cracks, corrosion, and prior repairs.
