JLG G9-43A Telehandler
JLG G9-43A
5+
sold in last yearGeneral overview
JLG G9-43A is a JLG construction equipment model used for lift and material-handling work on jobsites. It is powered by a John Deere 4045TF150 engine rated at 73 kW (99 hp) and has an operating weight of 12,150 kg (26,790 lb).
Its drivetrain uses a powershift transmission with 4F / 3R, torque-converter, full-time 4WD layout. It uses a front axle with planetary drive axle and limited slip differential, along with an oscillating rear axle. The hydraulic system is 151 L (40 US gal), with pump flow of 170 L/min (44.9 gpm) and system relief pressure of 206.8 bar (3,000 psi), and operator control is through a single multi-function hydraulic joystick for boom lift, telescope, and attachment tilt, plus a steering mode selector for 2-wheel, 4-wheel, and crab steering.
Year
2011, 2012, 2013, 2014, 2015
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
6,070 mm
~239 in
2,438 mm
~96 in
2,413 mm
~95 in
Operating Weight
12,150 kg
Power
99 hp
Boom Lift Capacity
3,175 kg
Maximum Lift Height
13.1 m
Additional specifications
Displacement
4 cu(m)
Transmission type
Powershift, 4F / 3R, torque-converter, full-time 4WD
Fuel tank
141 L
Gears
Oscillating rear axle
Control
Single multi-function hydraulic joystick for boom lift, telescope, and attachment tilt; steering mode selector (2-wheel, 4-wheel, crab)
Main Pumps
L/sec
System Relief Pressure
20,684 kPa
Engine Model
John Deere 4,045TF,150
Pump Flow
170 L/min
Hydraulic System
151 L
Lights
Front work lights; additional work lights available as options
Rated Operating Capacity
4,082 kg
Front Axle
Planetary drive axle with limited slip differential
Cylinders
4
JLG G9-43A Telehandler Listings
Looking for JLG G9-43A Telehandler?
See similar listingsCompare JLG G9-43A Telehandler to other telehandler
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a JLG G9-43A?
No confirmed market price is supplied. Check current listings and compare the machine’s condition, location, and configuration.
What are the key advantages of the JLG G9-43A?
Listed features include full-time 4WD, a planetary-drive front axle with limited-slip differential, an oscillating rear axle, and selectable 2-wheel, 4-wheel, and crab steering. A single multi-function hydraulic joystick controls boom lift, telescope, and attachment tilt.
What type of engine does the G9-43A use?
The G9-43A uses a John Deere 4045TF150 engine with 4 cylinders.
How much horsepower does the G9-43A have?
The G9-43A is rated at 99 hp.
What fuel does the JLG G9-43A use?
The supplied specifications do not confirm the fuel type for the JLG G9-43A.
What jobs is this Other construction equipment best suited for?
The supplied data does not identify specific job applications. Its listed controls, full-time 4WD, selectable steering modes, and boom and attachment functions may be relevant when assessing site-access and material-handling needs.
What is the expected lifespan of the G9-43A?
The supplied data does not provide an expected service life. For a used machine, assess maintenance records, operating condition, hydraulic performance, drivetrain operation, steering modes, and signs of leaks or wear.
What should a buyer check when purchasing a used Other construction equipment?
Check maintenance records, operating condition, hydraulic functions, boom lift and telescope controls, attachment tilt, steering modes, drivetrain operation, axle condition, lights, fluid leaks, and overall structural wear. Confirm that the machine matches the required configuration and job needs.
