J I CASE 2290 Row Crop Tractors
J I CASE 2290
5+
sold in last yearGeneral overview
J I CASE 2290 is a farm tractor produced from 1978 to 1983 in the United States. It is a wheel-type tractor powered by an 8 L diesel engine rated at 95 kW (129 hp). Built for general farm work, it combines engine output with a layout intended for routine field and implement tasks.
The 2290 was offered with an 8-speed gear standard transmission and a 12-speed partial powershift optional transmission. It is listed as 2WD with optional MFWD, and it uses an independent rear PTO with 540 and 1000 speeds. Other key features include a Category II rear 3-point hitch, draft and position control, a closed center hydraulic system, 79 L/min (20.9 gpm) pump output, and a maximum lift capacity behind the lift points of 3,107 kg (6,850 lb).
Year
1978, 1979, 1980, 1981, 1982, 1983
Country of manufacturing
United States
General specifications
Dimensions
Length
Weight
3,710 mm
~146.1 in
4,838 kg
~10,666 lb
Tire or Track Type
wheels
Engine Power
129 hp
Additional specifications
Engine type
diesel
Displacement
8 cu(m)
Maximum PTO power
129 hp
Rated PTO power
129 hp
Transmission type
8-speed gear standard; 12-speed partial powershift optional
Maximum lift capacity behind lift points
3,107 kg
Fuel tank
246 L
Hydraulic system type
closed center
Pump rated output
79 L/min
Number of rear selective control valves
2
Sensing type
draft and position control
Hitch type
2
Rear PTO
independent
Front Axle
2WD with optional MFWD
Rear 3-Point Hitch
Category II
Tire width
467 mm
Additional Options
ROPS or cab with A/C; MFWD optional; 8F/4R standard transmission; 12F/3R partial powershift optional
Tire type
bias-ply agricultural
PTO speed
["540", "1,000"]
Tire Size
10.00-16 front, 18.4-34 rear
J I CASE 2290 Row Crop Tractors Listings
Looking for J I CASE 2290 Row Crop Tractors?
See similar listingsCompare J I CASE 2290 Row Crop Tractor to other row crop tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a J I CASE 2290?
No confirmed market price is supplied. Check current listings and compare condition, location, hours, maintenance history, and installed configuration.
What are the key advantages of the J I CASE 2290?
Key listed features include a diesel engine rated at 96.2 kW (129 hp), independent rear PTO with 540 and 1000 speeds, closed-center hydraulics, draft and position control, and a Category II rear hitch. Cab with A/C and MFWD were optional.
What type of engine does the 2290 use?
The 2290 uses a diesel engine.
How much horsepower does the 2290 have?
The engine is rated at 96.2 kW (129 hp). Rated and maximum PTO power are also listed as 96.2 kW (129 hp).
What fuel does the J I CASE 2290 use?
The J I CASE 2290 uses diesel fuel. Its fuel tank capacity is listed as 246 L (65 US gal).
What jobs is this Tractors best suited for?
The supplied specifications do not confirm particular jobs. Its listed PTO, Category II rear hitch, hydraulic system, and rear selective control valves indicate it can be evaluated for work requiring compatible rear-mounted implements and hydraulic functions.
What is the expected lifespan of the 2290?
The supplied data does not provide an expected service-life estimate. For a used tractor, lifespan depends on maintenance, operating history, engine and transmission condition, hydraulic performance, and the condition of the hitch, PTO, and tires.
What should a buyer check when purchasing a used Tractors?
Check engine starting and operation, transmission shifting, PTO engagement, hydraulic output and rear valves, hitch lift and draft/position control, tire condition, steering and axle condition, leaks, brakes, electrical system, and maintenance records. Confirm whether it has MFWD, a cab, or ROPS.
