Hitachi Z50U Compact & Mini (Tracked) Excavators
Hitachi Z50U
5+
sold in last yearGeneral overview
Hitachi Z50U is an excavator for construction and earthmoving work. It has an operating weight of 5,395 kg (11,890 lb) and a net power rating of 26 kW (36 hp), giving it a practical size for digging and material-handling tasks on job sites. Manufactured in Japan, the model is part of Hitachi’s excavator lineup for construction applications.
The Z50U uses a Yanmar 4TNV88C 4-cylinder engine with Tier 4 Final emissions compliance and 2 L displacement. Hydraulic output is provided by a gear pump with a maximum rated flow of 31 L/min (8.2 gpm) and system relief pressure of 245 bar (3,550 psi). It offers a maximum digging depth of 3,835 mm (12 ft 7 in) and a maximum reach at ground level of 6,120 mm (20 ft 1 in).
Year
2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
Japan
General specifications
Dimensions
Length
Width
5,546 mm
~218.3 in
2,012 mm
~79.2 in
Emission standard level
Tier 4 Final
Displacement
2 cu(m)
Fuel tank
87 L
Alternator output
55
Number of batteries
1
Cooling system
8 L
Number of Cylinders
4
Dimensions
mm
Width
2,000 mm
Operating Weight
5,395 kg
Drawbar Pull
38 kN
Maximum Rated Flow
31 L/min
System Relief Pressure
24,500 kPa
Hydraulic Pumps
cu(cm)
Hydraulic Capacity
55 L
Engine Model
Yanmar 4TNV88C
Maximum Travel Speed - Low
2 km/h
Maximum Travel Speed - High
4 km/h
Maximum Pressure - Travel
24,500 kPa
Maximum Pressure - Swing
18,300 kPa
Engine Oil
5 L
Hydraulic System - Including Tank
87 L
Shipping Height - Top of Cab
2,510 mm
Tail Swing Radius
2,200 mm
Track Gauge
1,380 mm
Maximum Digging Depth
3,835 mm
Maximum Reach at Ground Level
6,120 mm
Maximum Cutting Height
5,740 mm
Maximum Loading Height
4,065 mm
Minimum Loading Height
365 mm
Maximum Vertical Wall Digging Depth
2,743 mm
Bucket Digging Force - ISO
6 kN
Boom length
1,380 mm
Net Power (ISO 9249)
36 hp
Hydraulic Pump
Gear pump
Maximum Operating Pressure
24,500 kPa
Additional specifications
Rated power
29.4 kW
Reference Bucket Capacity
0.22 cu(m)
Additional Options
Telematics system, USB power outlet (cab), work lights, motion alarm (with cancel switch), travel mode indicator, power/economy mode, boom cylinder guard, hose protectors, operator manual storage, fore/aft seat adjustment
Hitachi Z50U Compact & Mini (Tracked) Excavators Listings
Looking for Hitachi Z50U Compact & Mini (Tracked) Excavators?
See similar listingsCompare Hitachi Z50U Compact & Mini (Tracked) Excavator to other compact & mini (tracked) excavators
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Hitachi Z50U Compact & Mini (Tracked) Excavator
5395 kg
5546 mm × 2012 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Hitachi Z50U?
No confirmed market price is supplied for the Hitachi Z50U. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the Hitachi Z50U?
Listed strengths include a compact 2,000 mm width, 3,835 mm maximum digging depth, 6,120 mm maximum reach at ground level, and 26.8 kW (36 hp) net power. The machine also has a Tier 4 Final Yanmar 4TNV88C engine.
What type of engine does the Z50U use?
The Z50U uses a Yanmar 4TNV88C engine. It has 4 cylinders and is listed as meeting Tier 4 Final emissions requirements.
How much horsepower does the Z50U have?
The Z50U has a net power rating of 26.8 kW (36 hp) under ISO 9249.
What fuel does the Hitachi Z50U use?
The supplied specifications do not confirm the fuel type for the Hitachi Z50U. They list an 87 L (23 US gal) fuel tank.
What jobs is this Excavators best suited for?
The supplied data does not identify specific job applications. Buyers can compare the 3,835 mm maximum digging depth, 6,120 mm ground-level reach, 2,000 mm width, and 5,395 kg operating weight with their site and attachment requirements.
What is the expected lifespan of the Z50U?
The supplied data does not provide an expected service life for the Z50U. For a used machine, assess maintenance records, hydraulic performance, engine condition, undercarriage wear, structural damage, and any fluid leaks.
What should a buyer check when purchasing a used Excavators?
Check maintenance records, engine starting and operation, hydraulic response and leaks, boom and bucket joint wear, undercarriage condition, track wear, cab controls, safety equipment, and evidence of structural repairs. Confirm that the machine’s dimensions, digging depth, reach, and attachments fit the intended work.
