Farm King 1684 Grain Auger
Farm King 1684
5+
sold in last yearGeneral overview
Farm King 1684 is a grain auger for transferring harvested grain in farm handling operations. Manufactured in Canada, it is configured for tractor PTO use at 1,000 rpm and has a recommended PTO horsepower of 110 kW (150 hp). The intake uses a 406 mm (16 in) diameter, supporting grain movement through farm handling systems.
Key operating dimensions and handling characteristics include Reach - Raised: 12,192 mm (40 ft), Height - Raised: 5,486 mm (18 ft), Transport Length: 25,654 mm (84 ft 2 in), and Weight - Hitch: 998 kg (2,200 lb). Lift Mechanism: Scissor lift system with hydraulic winch; safety ball valve lever locks hydraulic lift, helping position the auger during setup and relocation.
Year
2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
Canada
General specifications
Dimensions
Length
Height
Width
25,603 mm
~1,008 in
4,013 mm
~158 in
2,921 mm
~115 in
Tractor PTO speed
1,000
Capacity (bushels per hour)
145,000 L/min
Recommended PTO Horsepower
150 hp
Tractor PTO RPM
1,000
Additional specifications
Drive type
PTO
Axle
6-bolt hubs
Recommended Horsepower - Electric
15 hp
HP Intake Diameter
406 mm
Height - Raised
5,486 mm
Height - Raised (with AugerMOVER)
6,706 mm
Reach - Lowered
2,438 mm
Reach - Raised
12,192 mm
Reach - Intake
1,524 mm
Tube Thickness
3,5 mm
Flighting - Standard Intake
1/4" thick (6.35 mm) on swing and main auger
Flighting - HP Intake
1 mm
Flighting - Main
1/4" thick (6.35 mm); heavy-duty, 11-gauge
1/4" Core Diameter
406 mm
Top Drive Chain
#80 chain
Transport Length
25,654 mm
Transport Height
4,013 mm
Wheel Track Width
4,064 mm
Lower Bearing Size
50 mm
Gearbox Shaft Diameter
38 mm
Weight - Hitch
998 kg
Frame Arms
Steel bridging & cables for reinforced upper support
Hydraulic Requirements
Dual spool valve option (powers intake hopper winch and mover with 2 remote valves); hydraulic swing hopper
Tire Size
11L x 15
Tire Ply Rating
8
Lift Mechanism
Scissor lift system with hydraulic winch; safety ball valve lever locks hydraulic lift
Farm King 1684 Grain Auger Listings
Looking for Farm King 1684 Grain Auger?
See similar listingsCompare Farm King 1684 Grain Auger to other grain auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Farm King 1684?
No confirmed market price is supplied for the Farm King 1684. Check current listings and compare the machine’s condition, location, and configuration.
What are the key advantages of the Farm King 1684?
Listed features include a scissor lift system with hydraulic winch, a safety ball valve lever that locks the hydraulic lift, hydraulic swing hopper, reinforced upper support with steel bridging and cables, and a dual spool valve option for the intake hopper winch and mover.
What type of engine does the 1684 use?
No engine type is specified. The Farm King 1684 lists PTO and electric horsepower recommendations, indicating it can be configured around those power sources rather than providing an onboard engine specification.
How much horsepower does the 1684 have?
The recommended PTO horsepower is 111.9 kW (150 hp), with a tractor PTO speed of 1,000 rpm. The recommended electric horsepower is 11.2 kW (15 hp).
What fuel does the Farm King 1684 use?
No fuel type is specified for the Farm King 1684. The supplied information lists PTO and electric horsepower recommendations but does not identify a fuel source.
What jobs is this Grain Auger best suited for?
As a Grain Auger, the Farm King 1684 is suited to grain-handling tasks that require an auger with a raised reach of 12,192 mm (480 in) and a hydraulic swing hopper. Specific crop, bin, and operating applications are not supplied.
What is the expected lifespan of the 1684?
The supplied information does not confirm an expected service life. For a used unit, inspect the tube, flighting, bearings, drive chain, gearbox shaft, lift system, hydraulics, tires, and frame support components for wear or damage.
What should a buyer check when purchasing a used Grain Auger?
Check the tube and flighting for wear, the lower bearing and gearbox shaft for play, the #80 top drive chain, hydraulic swing hopper and lift operation, tire condition, axle hubs, frame arms, cables, and safety ball valve lever. Confirm that the PTO or electric setup matches the intended power source.
