E-Z-GO EXPRESS 4 UTVs
E-Z-GO EXPRESS 4
Average price
$6,900
5+
sold in last year
General overview
The E-Z-GO EXPRESS 4 is a farm utility vehicle in the ATVs and Gators category, intended for general support work in agricultural settings. It is powered by a 10 kW (13 hp) 4-Cycle 24.5 in³ (401 cc), Single Cylinder OHV engine and has a 22 L (6 US gal) fuel capacity.
Its drivetrain uses a Continuously Variable Transmission (CVT) with rear-wheel drive and a differential with helical gears. The listed 1,660 mm (5 ft 5 in) wheelbase, Rear Wheel Mechanical Self-Adjusting Drum brakes, and Self-Compensating, Single Point Engagement park brake define a compact layout for routine on-site operation. A 12 V battery is also specified.
Year
2020
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
2,930 mm
~115.4 in
1,330 mm
~52.4 in
1,230 mm
~48.4 in
Engine Power
13 hp
Engine type
4-Cycle 24.5 in³ (401 cc), Single Cylinder OHV
Displacement
cu(m)
Transmission type
Continuously Variable Transmission (CVT) with clutch enclosure
Fuel capacity
22 L
Cooling system
5 L
Wheelbase
1,660 mm
Drive type
Rear-wheel drive
Battery Voltage
12
Towing capacity
680 kg
Brakes type
Rear Wheel Mechanical Self-Adjusting Drum
Park brake
Self-Compensating, Single Point Engagement
Drivetrain
Continuously Variable Transmission (CVT)
Final drive
Differential with Helical Gears
Four wheel drive
No
Traction assist
Limited slip front differential, Positive locking, switch actuated rear differential lock
Descent control
Not equipped
Final Drive
Park, high, low, neutral, reverse transaxle
Cargo box dimensions
1,143 x 305 x 1,320 mm
Cargo box capacity (weight)
454 kg
Front suspension
Fully independent dual A-arm with adjustable coils; 203 mm (8 in.) of travel
Rear suspension
Fully independent dual A-arm with adjustable coils and sway bar; 229 mm (9 in.) of travel
E-Z-GO EXPRESS 4 UTVs Listings
$6,900
4-Cycle 24.5 in³ (401 cc), Single Cylinder OHV
22 L
1660 mm
Holgate, United States
Compare E-Z-GO EXPRESS 4 UTV to other utvs
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a E-Z-GO EXPRESS 4?
No confirmed market price is supplied for the E-Z-GO EXPRESS 4. Check current listings and compare condition, location, and configuration.
What are the key advantages of the E-Z-GO EXPRESS 4?
Listed features include a 9.7 kW (13 hp) engine, Continuously Variable Transmission (CVT), rear-wheel drive, a differential with helical gears, and Rear Wheel Mechanical Self-Adjusting Drum brakes. Fuel capacity is 22 L (5.8 US gal).
What type of engine does the EXPRESS 4 use?
The EXPRESS 4 uses a 4-Cycle 24.5 in³ (401 cc), Single Cylinder OHV engine.
How much horsepower does the EXPRESS 4 have?
The EXPRESS 4 is rated at 13 hp (9.7 kW).
What fuel does the E-Z-GO EXPRESS 4 use?
The supplied specifications list a 22 L (5.8 US gal) fuel capacity but do not confirm the fuel type.
What jobs is this ATVs and Gators best suited for?
The supplied data does not identify specific jobs for this ATVs and Gators. Its listed rear-wheel drive and CVT configuration can be considered when matching the unit to the intended operating conditions.
What is the expected lifespan of the EXPRESS 4?
No expected service-life estimate is supplied for the EXPRESS 4. Condition, maintenance history, operating environment, and inspection results are more useful for evaluating an individual unit.
What should a buyer check when purchasing a used ATVs and Gators?
Check the engine operation, CVT response, rear-wheel drive and differential operation, brake function, parking brake, battery condition, fuel system, frame, tires, and maintenance records. Test the unit under normal operating conditions where possible.
