John Deere 524KII Wheel Loaders
DEERE 524KII
5+
sold in last yearGeneral overview
DEERE 524KII is a Wheel Loader designed for construction loading and material-handling work. The model is powered by a John Deere PowerTech PVS 6068 engine rated at 102 kW (139 hp), and it meets Tier 4 Final emission standards. It was produced from 2017 to 2019 in the United States.
With an operating weight of 12,670 kg (27,930 lb), the 524KII sits in a medium-size class suited to site loading and stockpile work. It offers a General Purpose capacity of 1 m³ (1.3 cu yd) and a Light Material capacity of 3 m³ (3.9 cu yd). Key operating dimensions include a load over height of 3,760 mm (12 ft 4 in), a reach at maximum dump height of 1,440 mm (4 ft 9 in), and a turning radius over bucket of 12,146 mm (39 ft 10 in).
Year
2017, 2018, 2019
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
7,340 mm
~289 in
3,250 mm
~128 in
2,550 mm
~100.4 in
Engine Power
139 hp
Operating Weight
12,670 kg
Bucket Capacity
2.1 cu(m)
Bucket Capacity - Heaped
1 cu(m)
Additional specifications
Emission standard level
Tier 4 Final
Displacement
6 cu(m)
Fuel tank
220 L
Cooling system
118 L
Height to top of cab
3,260 mm
Wheelbase
2,743 mm
Ground clearance with standard tires
400 mm
Battery Voltage
24
Width
2,550 mm
System Relief Pressure
1,724 kPa
Engine Model
John Deere PowerTech PVS 6,068
Battery Capacity
100
Engine Oil
18 L
Power - Net
139 hp
General Purpose
1 cu(m)
Light Material
3 cu(m)
Overall Length - With Bucket
7,280 mm
Reach at Maximum Dump Height
1,440 mm
Load Over Height
3,760 mm
Hinge Pin at Maximum Height
3,760 mm
Turning Radius - Over Bucket
12,146 mm
Width - Over Bucket
2,540 mm
Hydraulic System
18 L
Rated Operating Capacity
9,528 kg
John Deere 524KII Wheel Loaders Listings
Looking for John Deere 524KII Wheel Loaders?
See similar listingsCompare John Deere 524KII Wheel Loader to other wheel loaders
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a DEERE 524KII?
No confirmed market price is supplied for the DEERE 524KII. Check current listings and compare condition, location, and configuration.
What are the key advantages of the DEERE 524KII?
Listed strengths include 103.7 kW (139 hp) net power, a Tier 4 Final John Deere PowerTech PVS 6068 engine, and bucket options including General Purpose and Light Material.
What type of engine does the 524KII use?
The 524KII uses a John Deere PowerTech PVS 6068 engine. The listed emission standard level is Tier 4 Final.
How much horsepower does the 524KII have?
The 524KII has 103.7 kW (139 hp) of net power.
What fuel does the DEERE 524KII use?
The supplied specifications do not confirm the fuel type for the DEERE 524KII. They list a 220 L (58.1 US gal) fuel tank.
What jobs is this Wheel Loaders best suited for?
The supplied data lists General Purpose and Light Material bucket capacities, indicating suitability for loading and moving those material types. Exact job suitability depends on the bucket, configuration, and site conditions.
What is the expected lifespan of the 524KII?
The supplied data does not provide an expected service-life estimate for the 524KII. Inspect maintenance records, engine condition, hydraulics, tires, articulation, and bucket linkage when evaluating a machine.
What should a buyer check when purchasing a used Wheel Loaders?
Check service records, engine operation, hydraulic leaks and response, articulation joint wear, tires, brakes, bucket and linkage wear, cab controls, and signs of structural damage. Verify that the installed bucket and configuration suit the intended work.
