Caterpillar IT28G Wheel Loaders
Caterpillar IT28G
Average price
$31,500
5+
sold in last year
General overview
The Caterpillar IT28G is a wheel loader used for construction loading and material-handling tasks. It is powered by a 3056E engine rated at 115 kW (156 hp), and its operating weight is 12,134 kg (26,750 lb). Production is listed for 1999 in the United States.
The IT28G has a heaped bucket capacity of 2 m³ (2.6 cu yd) and a net power rating of 107 kW (145 hp). It is specified with a forward travel speed of 38 km/h (23.6 mph), a width of 2,540 mm (8 ft 4 in), and a turning radius over bucket of 5,070 mm (16 ft 8 in). The machine also lists a load over height of 3,694 mm (12 ft 1 in), a hinge pin at maximum height of 3,980 mm (13 ft 1 in), and a 6-cylinder, 6 L engine.
Year
1999
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
7,256 mm
~285.7 in
3,268 mm
~128.7 in
2,440 mm
~96.1 in
Engine Power
156 hp
Operating Weight
12,134 kg
Bucket Capacity
2 cu(m)
Bucket Capacity - Heaped
2 cu(m)
Additional specifications
Displacement
6 cu(m)
Fuel tank
225 L
Cooling system
42 L
Height to top of cab
3,268 mm
Wheelbase
2,900 mm
Number of Cylinders
6
Ground clearance with standard tires
407 mm
Battery Voltage
24
Width
2,540 mm
System Relief Pressure
20,700 kPa
Travel Speed Forward
38 km/h
Engine Model
3,056E
Engine Oil
16 L
Power - Net
145 hp
Net Power (ISO 9249)
145 hp
Hydraulic Cycle Time - Lower, Float
2 s
Hydraulic Cycle Time - Lift
6 s
Hydraulic Cycle Time - Dump
1 s
Overall Length - With Bucket
7,256 mm
Reach at Maximum Dump Height
958 mm
Dig Depth
108 mm
Load Over Height
3,694 mm
Hinge Pin at Maximum Height
3,980 mm
Overall Length - With Forks
7,557 mm
Fork Height at Maximum Reach
3,843 mm
Turning Radius - Over Bucket
5,070 mm
Width - Over Bucket
2,440 mm
Dump Angle at Maximum Height
45 deg
Hydraulic System
125 L
Rated Operating Capacity
3,194 kg
Caterpillar IT28G Wheel Loaders Listings
Compare Caterpillar IT28G Wheel Loader to other wheel loaders
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Caterpillar IT28G?
No confirmed market price is supplied for the Caterpillar IT28G. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the Caterpillar IT28G?
The supplied specifications list a 2 m³ (2.62 cu yd) heaped bucket capacity, 116.3 kW (156 hp) engine power, 38 km/h (23.6 mph) forward travel speed, and 6 s lift cycle time. These specifications can help buyers assess suitability for their operating needs.
What type of engine does the IT28G use?
The Caterpillar IT28G uses a 3056E engine with 6 cylinders.
How much horsepower does the IT28G have?
The Caterpillar IT28G has 116.3 kW (156 hp) engine power. Its net power is 108.1 kW (145 hp), including Net Power (ISO 9249).
What fuel does the Caterpillar IT28G use?
The supplied data does not confirm the fuel type for the Caterpillar IT28G.
What jobs is this Wheel Loaders best suited for?
The supplied data identifies the Caterpillar IT28G as a Wheel Loaders model and lists a 2 m³ (2.62 cu yd) heaped bucket capacity. The data does not confirm specific job applications; match the bucket, forks, hydraulic requirements, and site conditions to the intended work.
What is the expected lifespan of the IT28G?
The supplied data does not provide an expected service life for the IT28G. Evaluate maintenance records, operating hours, structural condition, hydraulic performance, engine condition, and tire wear when assessing a particular machine.
What should a buyer check when purchasing a used Wheel Loaders?
Check maintenance records, engine operation, hydraulic leaks and cycle performance, bucket or fork condition, articulation and steering play, tire wear, brakes, electrical system, cab condition, and signs of frame damage or repairs. Test the machine under load if possible.
