Caterpillar 420E IT Backhoe Loaders
Caterpillar 420E IT
5+
sold in last yearGeneral overview
Caterpillar 420E IT is a backhoe loader designed for excavation and loading work in construction settings. It uses a Cat C4.4 ACERT DIT engine rated at 68 kW (93 hp), with Tier 3 emissions, and the machine is identified with 4 cylinders and a 4 L displacement. This configuration places it in a compact-to-mid-size construction class suited to mixed digging and material-handling duties.
The model has an operating weight of 7,025 kg (15,490 lb) and an Auto-Shift / Powershift transmission with 4-speed fwd/rev operation. Backhoe hydraulics use closed center, load sensing controls with a main variable-flow, axial piston pump rated at 163 L/min (43.1 gpm). It offers a maximum SAE digging depth of 5,456 mm (17 ft 11 in) and a reach from center of swing pivot of 5,638 mm (18 ft 6 in).
Year
2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
5,800 mm
~228.3 in
2,800 mm
~110.2 in
2,400 mm
~94.5 in
Engine Power
93 hp
Operating Weight
7,025 kg
Dig Depth
4,360 mm
Capacity Bucket (loader)
cu(m)
Capacity Bucket (backhoe)
0.96 cu(m)
Digging Depth (SAE)
4.36 m
Additional specifications
Emission standard level
Tier 3
Displacement
4 cu(m)
Tires front
11L-16 F-3 / 12.5/80-18 (10 ply) Super Traction
Transmission type
Auto-Shift / Powershift (4-speed fwd/rev)
Fuel tank
144 L
Overall length w/header
7,500 mm
Height to top of cab
2,800 mm
Wheelbase
2,210 mm
Number of Cylinders
4
Tires rear
19.5L-24 (12 ply) R4 ATU / IT 525
Ground clearance with standard tires
320 mm
Battery Voltage
12
Bucket Width
610 mm
Hydraulic Capacity
79 L
Engine Model
Cat C4.4 ACERT DIT (standard) / 3,054C DIT (early)
Engine Oil
16 L
Power - Net
89 hp
Net Power (ISO 9249)
97 hp
Bucket Weight
438 kg
Bucket Range
2,262 mm
Pump flow backhoe
163 L/min
Pump flow loader
163 L/min
Controls backhoe
Closed center, load sensing
Controls loader
Closed center, load sensing
Operating Weights with Full Fuel Tank, Standard Equipment
7,025 kg
Operating Weights typical with Cab, Extendable Dipperstick and Counterweight
10,700 kg
Length From Axle to Axle
2,210 mm
Reach From Center of Swing Pivot
5,638 mm
Digging Depth (SAE maximum)
5,456 mm
Height to Bucket Hinge Pin, Maximum
2,573 mm
Dump Clearance
2,573 mm
Main Pump Type
Variable-flow, axial piston
Rated Operating Capacity
2,875.28 kg
Caterpillar 420E IT Backhoe Loaders Listings
Looking for Caterpillar 420E IT Backhoe Loaders?
See similar listingsCompare Caterpillar 420E IT Backhoe Loader to other backhoe loaders
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Caterpillar 420E IT Backhoe Loader
4360 mm
5800 mm × 2400 mm × 2800 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Caterpillar 420E IT?
No confirmed market price is supplied for the Caterpillar 420E IT. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the Caterpillar 420E IT?
The supplied specifications list a 4-speed Auto-Shift / Powershift transmission, closed-center load-sensing controls for both loader and backhoe functions, and variable-flow axial-piston hydraulic pumping. Listed digging depth is 5,456 mm (214.8 in) SAE maximum, with 163 L/min (43.1 gpm) pump flow.
What type of engine does the 420E IT use?
The 420E IT uses a Cat C4.4 ACERT DIT engine as standard. Early machines are listed with a 3054C DIT engine. Both listings indicate a 4-cylinder engine and Tier 3 emission standard level.
How much horsepower does the 420E IT have?
Engine Power is listed as 69.4 kW (93 hp). The specifications also list Power - Net at 66.4 kW (89 hp) and Net Power (ISO 9249) at 72.3 kW (97 hp).
What fuel does the Caterpillar 420E IT use?
The supplied specifications do not confirm the fuel type. They list a fuel tank capacity of 144 L (38 US gal).
What jobs is this Backhoe Loaders best suited for?
Its listed backhoe and loader hydraulic flow, digging depth, and loader dump clearance indicate suitability for general excavation, trenching, loading, and material-handling work. Confirm the attachment setup, tire choice, and site requirements for the intended job.
What is the expected lifespan of the 420E IT?
The supplied data does not provide an expected service life for the 420E IT. For a used machine, assess maintenance records, hydraulic performance, engine condition, transmission operation, structural wear, and signs of leaks.
What should a buyer check when purchasing a used Backhoe Loaders?
Check the engine, transmission, hydraulic pump and controls, loader and backhoe linkage, bucket wear, tires, frame, and cab. Test digging, loading, steering, and braking functions. Review service records and inspect for fluid leaks, damage, and excessive play in pivots.
