Brent 576 Gravity
Brent 576
5+
sold in last yearGeneral overview
The Brent 576 grain cart is a farm equipment attachment used in harvest grain handling, moving crop from the field to the next transfer point. It is specified with a power requirement of 96 kW (130 hp) and a peak unloading rate of 10,571 L/min (2,792.6 gpm), placing it in a higher-capacity cart class for rapid grain transfer.
For tractor compatibility, the tongue-mounted hydraulic drive option requires approximately 55 US gpm (≈208.2 L/min) and two hydraulic ports/sets. The cart is listed at 2,948 kg (6,500 lb) empty, with a hitch weight loaded of 1,456 kg (3,210 lb). It uses a 355 mm (14 in) vertical auger and 355 mm (14 in) horizontal auger, plus an exclusive heavy-duty 45° gearbox with 1 3/4" output shaft; static rated 330 HP, dynamic rated 153 HP.
Year
2015
Country of manufacturing
United States
General specifications
Grain Cart Capacity
19,439.61 L
Hub Size/Spindle Diameter
2-7/8
Front/Rear Slopes
Steep-sloped sides; front slope 45°, rear slope 45°
Back Slope
45 deg
Door Width
0.91 m
Chute Height
3.4 m (11 ft 2 in)
Unloading Time
110 s
Grain Cart Wheel Size
High-flotation single tires or duals; exact tire size unknown
Grain Cart Turning Radius
7.6 m (25 ft) outside turning radius
Additional specifications
Peak unloading rate
10,571 L/min
Power requirement
130 hp
Capacity Heaped
19,381 cu(m)
Tractor hydraulics requirements
Tongue-mounted hydraulic drive option requires approximately 55 US gpm (≈208.2 L/min) and two hydraulic ports/sets.
Total weight - empty
2,948 kg
Hitch weight - loaded
1,456 kg
Vertical auger
355 mm
Horizontal auger
355 mm
Gearbox
Exclusive heavy-duty 45° gearbox with 1 3/4" output shaft; static rated 330 HP, dynamic rated 153 HP.
Brent 576 Gravity Listings
Looking for Brent 576 Gravity?
See similar listingsCompare Brent 576 Gravity to other gravity
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Brent 576?
No confirmed market price is supplied for the Brent 576. Check current listings and compare condition, location, and configuration.
What are the key advantages of the Brent 576?
Listed features include a 19,381 m³ (25,349.38 cu yd) heaped capacity, a peak unloading rate of 10,571 L/min (2,792.6 gpm), and 355 mm (14 in) vertical and horizontal augers. It also has a heavy-duty 45° gearbox with a 1 3/4" output shaft.
What type of engine does the 576 use?
The supplied specifications do not identify an engine for the Brent 576. They list a power requirement of 96.9 kW (130 hp).
How much horsepower does the 576 have?
The Brent 576 has a listed power requirement of 96.9 kW (130 hp).
What fuel does the Brent 576 use?
The supplied information does not confirm a fuel type for the Brent 576.
What jobs is this Grain carts best suited for?
As a grain cart, the Brent 576 is suited to handling and unloading grain. Its listed 19,381 m³ (25,349.38 cu yd) heaped capacity and peak unloading rate of 10,571 L/min (2,792.6 gpm) are relevant to those tasks.
What is the expected lifespan of the 576?
The supplied data does not provide an expected service life for the Brent 576. Actual lifespan depends on maintenance, operating conditions, loading practices, and the condition of the augers, gearbox, hydraulics, and structure.
What should a buyer check when purchasing a used Grain carts?
Inspect the augers, gearbox, output shaft, hydraulic drive and hoses, hitch, tires, frame, and grain tank for wear, leaks, damage, or repairs. Verify unloading operation and hydraulic compatibility. For this model, confirm the required hydraulic flow and ports if equipped with the tongue-mounted hydraulic drive option.
