Brent 2096 Single Auger
Brent 2096
5+
sold in last year
General overview
Produced from 2014 to 2020, Brent 2096 is a grain cart used for handling harvested grain in field transfer and unloading operations during harvest. It is specified for a 294 kW (400 hp) tractor and requires 6 SCVs, with a 1000 rpm PTO requirement and a heavy-duty 90° direct-drive gearbox supporting the drive system.
The cart uses a belt-driven 20″ floor auger with 609 mm (24 in) vertical and 508 mm (20 in) horizontal augers. It is rated for a peak unloading rate of 587 L/s (16.7 bu/s) and has a hitch weight of 1,814 kg (4,000 lb) empty or 2,722 kg (6,000 lb) loaded. Optional equalizer tracks are available in 42″ × 148″ or 50″ × 148″ sizes.
Year
2014, 2020
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
3,658 mm
~144 in
4,242 mm
~167 in
11,560 mm
~455.1 in
16,620 kg
~36,640.9 lb
Unloading rate
23,643.12 L/min
Capacity Heaped
71 cu(m)
Grain Cart Capacity
56,633.6 L
Required Engine Power
298.28 kW
Grain Cart Loaded Tongue Weight
2,721.55 kg
Grain Cart Empty Tongue Weight
1,814.37 kg
Grain Cart Auger Diameter
0.61 m
Flighting Thickness
7/16
Hub Size/Spindle Diameter
-
Hydraulic Remotes Required
4
Front/Rear Slopes
45° front / 45° rear
Hopper Length
8.84 m
Hopper Width
4.22 m
Auger Side Reach Max
2.57 m
Auger Side Reach Min
1.55 m
Grain Cart Overall Transport Length
11.56 m
Additional specifications
Peak unloading rate
16.67 bu/sec
Power requirement
400 hp
PTO
1,000 rpm
Track size
optional equalizer tracks (42″ × 148″ or 50″ × 148″)
Tractor hydraulics requirements
6 SCVs
Total weight - empty
Hitch weight - empty
1,814 kg
Hitch weight - loaded
2,722 kg
Vertical auger
609 mm
Horizontal auger
508 mm
Gearbox
heavy-duty 90° direct-drive gearbox
Drive belts
belt-driven 20″ floor auger
Brent 2096 Single Auger Listings
$104,500
Heavy-duty 90° direct-drive gearbox
Optional equalizer tracks (42″ × 148″ or 50″ × 148″)
1000 rpm
Hastings, United States
Compare Brent 2096 Single Auger to other single auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Brent 2096?
No confirmed market price is supplied for the Brent 2096. Check current listings and compare the cart’s condition, location, and configuration.
What are the key advantages of the Brent 2096?
Listed features include 71 m³ (92.86 cu yd) heaped capacity, a peak unloading rate of 16.7 bu/s, a belt-driven 20″ floor auger, and a heavy-duty 90° direct-drive gearbox. Optional equalizer tracks are also available.
What type of engine does the 2096 use?
The supplied specifications do not identify an engine type for the Brent 2096. They list a tractor power requirement and a 1000 rpm PTO.
How much horsepower does the 2096 have?
The Brent 2096 has a listed tractor power requirement of 298.3 kW (400 hp). The supplied data does not state that the cart itself has an engine.
What fuel does the Brent 2096 use?
The supplied specifications do not state a fuel type for the Brent 2096. It requires tractor power and a 1000 rpm PTO.
What jobs is this Grain carts best suited for?
The Brent 2096 is a grain cart suited to handling and unloading grain during farm operations. Its listed 71 m³ (92.86 cu yd) heaped capacity and 16.7 bu/s peak unloading rate support grain transfer tasks.
What is the expected lifespan of the 2096?
The supplied data does not provide an expected service-life estimate for the Brent 2096. For a used cart, assess maintenance history, structural condition, augers, belts, gearbox, hydraulics, and tracks or tires.
What should a buyer check when purchasing a used Grain carts?
Inspect the cart structure, hitch, augers, drive belts, 90° direct-drive gearbox, PTO components, and hydraulic connections. Verify that the tractor can meet the 298.3 kW (400 hp), 6 SCVs, and 1000 rpm PTO requirements. Check track condition if equipped.
