Brent 1596 Single Auger
Brent 1596
5+
sold in last yearGeneral overview
Brent 1596 is a grain cart designed for field grain transfer during harvest. Produced in the United States from 2011 through 2021, this model is specified for 294 kW (400 hp) and is compatible with 1,000 rpm PTO operation or a hydraulic motor. It is used as a farm equipment attachment for moving harvested grain within the field.
The cart has an empty weight of 14,832 kg (32,700 lb) and a loaded hitch weight of 2,722 kg (6,000 lb). Grain movement is handled through a 559 mm (22 in) vertical auger and a 508 mm (20 in) horizontal auger, with a peak unloading rate of 17,640 L/min (4,660 gpm). The listed track size is 914 mm (36 in).
Year
2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
11,530 mm
~453.9 in
3,660 mm
~144.1 in
4,240 mm
~166.9 in
Unloading rate
11,576 L/min
Grain Cart Capacity
56,382.4 L
Required Engine Power
149.14 kW
Grain Cart Loaded Tongue Weight
1,905.09 kg
Grain Cart Empty Tongue Weight
1,315.42 kg
Grain Cart Auger Diameter
0.56 m
Flighting Thickness
0.64 cm
Hub Size/Spindle Diameter
10-bolt hub; spindle diameter Unknown
Hydraulic Remotes Required
2 hydraulic remotes
Front/Rear Slopes
Front 30°, rear 35°
Hopper Length
6.86 m
Hopper Width
4.27 m
Auger Side Reach Max
5.49 m
Auger Side Reach Min
3.05 m
Grain Cart Overall Transport Length
11.58 m
Additional specifications
Peak unloading rate
17,640 L/min
Power requirement
400 hp
Capacity Heaped
53,760 cu(m)
Track size
914 mm
Tractor hydraulics requirements
Compatible with 1,000 RPM PTO or hydraulic motor; hydraulic options commonly use 3 SCV remotes (no flow/pressure specs provided).
Total weight - empty
14,832 kg
Hitch weight - empty
1,723 kg
Hitch weight - loaded
2,722 kg
PSI capacity
87 kPa
Vertical auger
559 mm
Horizontal auger
508 mm
Gearbox
Brent-specified right-angle gearbox (no public model number)
Drive belts
Multiple V-belts (exact count and size not published; consult parts manual)
Drive sheaves
Multiple sheaves (exact sizes and count not published; consult parts manual)
PTO speed
1,000
Brent 1596 Single Auger Listings
Looking for Brent 1596 Single Auger?
See similar listingsCompare Brent 1596 Single Auger to other single auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Brent 1596?
No confirmed market price is supplied for the Brent 1596. Check current listings and compare condition, location, and configuration.
What are the key advantages of the Brent 1596?
Listed features include a peak unloading rate of 17,640 L/min (4,660 gpm), a 559 mm (22 in) vertical auger, a 508 mm (20 in) horizontal auger, and compatibility with 1000 RPM PTO or a hydraulic motor.
What type of engine does the 1596 use?
The supplied specifications do not identify an engine for the Brent 1596. It lists a power requirement and PTO or hydraulic-motor compatibility rather than an onboard engine.
How much horsepower does the 1596 have?
The Brent 1596 has a listed power requirement of 298.3 kW (400 hp).
What fuel does the Brent 1596 use?
The supplied data does not specify a fuel type for the Brent 1596. It is listed as compatible with 1000 RPM PTO or a hydraulic motor.
What jobs is this Grain carts best suited for?
As a grain cart, the Brent 1596 is suited to grain-handling and unloading work. Its listed peak unloading rate is 17,640 L/min (4,660 gpm). The supplied data does not provide more specific crop or field-use recommendations.
What is the expected lifespan of the 1596?
The supplied data does not provide an expected service life for the Brent 1596. Inspect the augers, gearbox, drive belts, sheaves, tracks, hitch, and hydraulic components, and review maintenance history when available.
What should a buyer check when purchasing a used Grain carts?
Check the augers for wear or damage, inspect the Brent-specified right-angle gearbox, drive belts, and sheaves, and examine the hitch and tracks. Verify PTO and hydraulic operation, including the required remotes if equipped with hydraulic unloading.
