Brandt 13x110xl+ Grain Auger
Brandt 13x110xl+
Average price
$49,500
5+
sold in last year
General overview
Brandt 13x110xl+ is a grain auger for farm grain handling and transfer. It is specified for a tractor PTO speed of 1,000 rpm and has an intake diameter of 330 mm (13 in), which identifies the model's intake size for grain movement. The standard intake and main flighting are both 9.5 mm (3/8") thick.
A scissor lift with 3 hydraulic cylinders supports positioning, and hydraulic requirements are listed as 45 L/min @ 2500 psi. The auger's working range extends to 9,754 mm (32 ft) lowered and 12,802 mm (42 ft) raised, with a raised height of 6,706 mm (22 ft), transport length of 13,360 mm (43 ft 10 in), and operating width of 1,981 mm (6 ft 6 in).
Year
2022, 2023, 2024, 2025, 2026
Country of manufacturing
Canada
General specifications
Dimensions
Length
Height
Width
13,360 mm
~526 in
6,100 mm
~240.2 in
3,658 mm
~144 in
Tractor PTO speed
1,000
Capacity (bushels per hour)
387,629,77 L/min
Recommended PTO Horsepower
134.23 kW
Tractor PTO RPM
540
Additional specifications
Drive type
PTO drive
Operating Weight
1,219 kg
Operating width
1,981 mm
Axle
100 mm (4") square tubing
Upper Bar Length
2,438 mm
HP Intake Diameter
330 mm
Height - Raised
6,706 mm
Reach - Lowered
9,754 mm
Reach - Raised
12,802 mm
Reach - Intake
2,438 mm
Tube Thickness
4,8 mm
Flighting - Standard Intake
9.5 mm (3/8") thick
Flighting - Main
9.5 mm (3/8") thick, 330 mm diameter
Transport Length
13,360 mm
Transport Height
6,100 mm
Wheel Track Width
3,658 mm
Lower Bearing Size
50 mm
Frame Arms
200 mm x 200 mm tubing
Number of Hydraulic Cylinders
3
Hydraulic Requirements
45 L/min @ 2,500 psi
Tire Size
500/45-20
Tire Ply Rating
6
Height w/ Extension
1,727 mm
Number of Wheels
4
Lift Mechanism
Scissor lift
Brandt 13x110xl+ Grain Auger Listings
Compare Brandt 13x110xl+ Grain Auger to other grain auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Brandt 13x110xl+ Grain Auger
387629,77 L/min
13360 mm × 3658 mm × 6100 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Brandt 13x110xl+?
No confirmed market price is supplied. Check current listings and compare the auger’s condition, location, and configuration.
What are the key advantages of the Brandt 13x110xl+?
Listed features include 387,629.8 L/min (102,400.9 gpm) capacity, a 12,802 mm (504 in) raised reach, scissor lift, three hydraulic cylinders, and four wheels.
What type of engine does the 13x110xl+ use?
The supplied specifications do not identify an engine. They list a tractor PTO speed requirement of 1,000 rpm.
How much horsepower does the 13x110xl+ have?
The supplied data does not confirm a horsepower rating for the 13x110xl+.
What fuel does the Brandt 13x110xl+ use?
The supplied data does not specify a fuel type. It identifies the unit as tractor PTO-driven at 1,000 rpm.
What jobs is this Grain Auger best suited for?
As a Grain Auger, it is suited for grain-moving tasks where its listed capacity and reach fit the operation. The supplied data lists 387,629.8 L/min (102,400.9 gpm) capacity and 12,802 mm (504 in) raised reach.
What is the expected lifespan of the 13x110xl+?
The supplied data does not provide an expected service life. Inspect the tube, flighting, bearings, hydraulic components, tires, and frame regularly, and maintain the PTO-driven system according to the applicable service guidance.
What should a buyer check when purchasing a used Grain Auger?
Check the tube and flighting for wear or damage, inspect bearings and hydraulic cylinders for leaks or play, and examine the frame, axle, wheels, tires, lift mechanism, and PTO connection. Verify that all operating and transport functions work properly.
