Bobcat T66 Skid Steer / CTL
Bobcat T66
Average price
$50,000
5+
sold in last year
General overview
The Bobcat T66 is a crawler loader designed for loading and grading work in construction settings. It combines a 54 kW (74 hp) engine with an operating weight of 3,728 kg (8,220 lb), giving it the tracked traction and working mass needed for material handling and earthmoving tasks on job sites.
The model uses a hydrostatic transmission, hydraulic joystick controls, and hydraulic steering with independent left and right track control for precise maneuverability. Its undercarriage includes a 1,570 mm (5 ft 2 in) track gauge, 300 mm (12 in) grousers, and 40.7 kPa (5.9 psi) ground pressure, while the bucket capacity is 1.1 m³ (1.4 cu yd). Tier 4 emissions compliance and 10.3 km/h (6.4 mph) travel speed further define its operating profile.
Year
2021, 2022, 2023, 2024
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
1,702 mm
~67 in
2,045 mm
~80.5 in
3,426 mm
~134.9 in
3,728 kg
~8,218.8 lb
Engine Power
74 hp
Operating Weight
3,728 kg
Bucket Capacity - Heaped
1.1 cu(m)
Rated Operating Capacity
1,115 kg
Additional specifications
Emission standard level
Tier 4
Displacement
2,400 cu(cm)
Transmission type
Hydrostatic
Fuel tank
107.1 L
Hydraulic system type
Standard or optional high-flow hydraulics
Number of batteries
2
Cooling system
14.4 L
Number of Cylinders
4
Battery Voltage
12 Volt
System Relief Pressure
22.761 kPa
Undercarriage Ground Pressure
40.7 kPa
Length of Track on Ground
1,368 mm
Number of Shoes
5
Hydraulic controls
Hydraulic joystick
Battery Capacity
850 CCA
Engine Oil
10.2 L
Hydraulic System - Including Tank
84.8 L
Track Gauge
1,570 mm
Net Power (ISO 9249)
74 hp
Manufacturer and Model
T66
Net Peak Torque
300 kN
Powertrain System Relief Pressure
22.761 psi
Travel Speeds
10.3 km/h
Steering
Hydraulic, with independent left and right track control for precise maneuverability
Drawbar Pull at 1.9 km/h (1.2 mph)
39 kN
Drawbar Pull at 3.2 km/h (2.0 mph)
31.8 kN
Pump Flow
64 L/min
Maximum Flow at Unloaded High Idle
101 L/min
Alternator Rating
90 amp
Grouser Width
300 mm
Track Rollers, Each Side
2
Ground Contact Area
15.484 sq(cm)
Track Pitch
63.5 mm
Hydraulic Tank
50.8 L
Width of Bucket (General Purpose)
1,830 mm
Capacity Heaped
1.1 cu(m)
Bucket Weight
363 kg
Breakout Force
27.76 kN
Static Tipping Load
1.996 kg
Width of Bucket (Multipurpose)
1,830 mm
Capacity Heaped Multipurpose
1.1 cu(m)
Bucket Weight (Multipurpose)
454 kg
Breakout Force (Buckets Multipurpose)
27.76 kN
Static Tipping Load (Buckets Multipurpose)
1.996 kg
Cab With Pressurizer and Heater/ Air Conditioner
136 kg
Lift-Cylinder Guards
43 kg
Full-Length Rock Guards
91 kg
Final-Drive Trash Guards
36 kg
Clam-Cylinder Protection for Multipurpose Bucket
22 kg
Retrieval Hitch
27 kg
Double-Bar Grousers
45 kg
Bobcat T66 Skid Steer / CTL Listings
$51,670
1.1 cu(m)
74 hp
3728 kg
590 hours
Pflugerville, United States
Compare Bobcat T66 Skid Steer / CTL to other skid steer / ctl
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Bobcat T66 Skid Steer / CTL
1.1 cu(m)
3728 kg
3426 mm × 1702 mm × 2045 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Bobcat T66?
No confirmed market price is supplied for the Bobcat T66. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the Bobcat T66?
Listed strengths include 55.2 kW (74 hp) net power, hydrostatic transmission, hydraulic joystick controls, and independent left and right track control. It also offers standard or optional high-flow hydraulics and a 1.1 m³ (1.44 cu yd) heaped bucket capacity.
What type of engine does the T66 use?
The supplied specifications do not identify the engine manufacturer or engine model. They list a 4-cylinder engine with 2,400 cc displacement, Tier 4 emissions level, and 55.2 kW (74 hp) net power.
How much horsepower does the T66 have?
The T66 has 74 hp of engine power. Its net power under ISO 9249 is also listed as 74 hp.
What fuel does the Bobcat T66 use?
The supplied specifications do not confirm the fuel type for the Bobcat T66. They list a fuel tank capacity of 107.1 L (28.3 US gal).
What jobs is this Crawler Loaders best suited for?
The listed bucket capacity, tracked undercarriage, and independent track control indicate suitability for material loading, carrying, and placement where maneuverability is needed. Hydraulic joystick controls and optional high-flow hydraulics may also support compatible hydraulic attachments, though specific attachment applications are not supplied.
What is the expected lifespan of the T66?
The supplied data does not provide an expected service life for the T66. Service life depends on operating conditions, maintenance history, undercarriage condition, hydraulic performance, and the condition of the engine and attachments.
What should a buyer check when purchasing a used Crawler Loaders?
Inspect the tracks, grousers, undercarriage, bucket, lift cylinders, hydraulic hoses, and controls. Check for leaks, verify hydraulic and travel operation, review maintenance records, and inspect the engine, cooling system, battery system, and safety equipment.
