Bobcat T650 Skid Steer / CTL
Bobcat T650
5+
sold in last yearGeneral overview
The Bobcat T650 is a crawler loader manufactured in the United States for construction loading, material handling, and general site work. It is powered by a Kubota V3307-DI-TE3 engine rated at 54 kW (74 hp) and has an operating weight of 4,134 kg (9,110 lb). The machine is listed with a Tier 4 emissions level.
A hydrostatic drive system with two-speed travel gives a top travel speed of 14 km/h (8.7 mph). The closed-center, load-sensing hydraulic system is paired with pilot-operated joystick controls, a pump flow of 87.1 L/min (23 gpm), and maximum flow at unloaded high idle of 193 L/min (51 gpm). The loader is specified with a heaped bucket capacity of 1.13 m³ (1.5 cu yd), a breakout force of 33 kN (7,420 lbf), and a static tipping load of 3,331 kg (7,340 lb).
Year
2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2025
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
1,851 mm
~72.9 in
2,065 mm
~81.3 in
3,474 mm
~136.8 in
4,134 kg
~9,113.9 lb
Engine Power
74 hp
Operating Weight
4,134 kg
Bucket Capacity - Heaped
1.13 cu(m)
Rated Operating Capacity
1,166 kg
Additional specifications
Emission standard level
Tier 4
Displacement
203.3 cu(in)
Transmission type
Hydrostatic drive system with two-speed travel
Fuel tank
166.4 L
Hydraulic system type
Closed-center, load-sensing
Number of batteries
1
Cooling system
11.4 L
Number of Cylinders
4
Battery Voltage
12 V
System Relief Pressure
3,550 psi
Undercarriage Ground Pressure
5.8 psi
Length of Track on Ground
1,464 mm
Hydraulic controls
Pilot-operated joystick controls with optional auxiliary hydraulics
Engine Oil
9.2 L
Hydraulic System - Including Tank
45 L
Track Gauge
1.853 mm
Net Power (ISO 9249)
70.5 hp
Manufacturer and Model
Kubota V3,307-DI-TE3
Net Peak Torque
264.4 Nm
Powertrain System Relief Pressure
3,500 psi
Travel Speeds
14 km/h
Steering
Hydrostatic, joystick-controlled, with independent track control for precise maneuverability
Drawbar Pull Maximum
31.1 kN
Drawbar Pull at 1.9 km/h (1.2 mph)
26.7 kN
Drawbar Pull at 3.2 km/h (2.0 mph)
24.5 kN
Pump Flow
87.1 L/min
Differential Pressure
15 kPa
Maximum Flow at Unloaded High Idle
193 L/min
Alternator Rating
90 amps
Grouser Width
320 mm
Width of Bucket (General Purpose)
1,880 mm
Capacity Heaped
1.13 cu(m)
Bucket Weight
101 kg
Breakout Force
33 kN
Static Tipping Load
3,331 kg
Pump Displacement
Bobcat T650 Skid Steer / CTL Listings
Looking for Bobcat T650 Skid Steer / CTL?
See similar listingsCompare Bobcat T650 Skid Steer / CTL to other skid steer / ctl
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Bobcat T650 Skid Steer / CTL
1.13 cu(m)
4134 kg
3474 mm × 1851 mm × 2065 mm
Add model
Add model
2.0
Rating
Based on ratings and reviews from verified buyers.
Overall rating
1 reviews
5
4
3
2
1
Performance & Productivity
1.0
Reliability & Durability
1.0
Comfort & Ergonomics
2.0
Safety
3.0
Technology & Features
1.0
Vernon Turner
We use it for mulching and brush cutting. The cooling package holds up on the hottest days at pallet work. Daily checks are easy to get at for service.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Bobcat T650?
No confirmed market price is supplied. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the Bobcat T650?
The listed advantages include a hydrostatic two-speed travel system, joystick-controlled independent track control, and a closed-center, load-sensing hydraulic system. It also has 55.2 kW (74 hp) of engine power, 87.1 L/min (23 gpm) pump flow, and 40 kPa (5.8 psi) undercarriage ground pressure.
What type of engine does the T650 use?
The T650 uses a Kubota V3307-DI-TE3 engine. It has 4 cylinders, 203.3 cu in displacement, and a Tier 4 emission standard level.
How much horsepower does the T650 have?
Engine power is 55.2 kW (74 hp). Net Power (ISO 9249) is 52.6 kW (70.5 hp).
What fuel does the Bobcat T650 use?
The supplied specifications do not confirm the fuel type for the Bobcat T650.
What jobs is this Crawler Loaders best suited for?
The supplied data supports use where tracked maneuverability, loader work, and hydraulic attachments are needed. Relevant features include independent track control, a 1.13 m³ (1.48 cu yd) heaped bucket capacity, optional auxiliary hydraulics, and 40 kPa (5.8 psi) ground pressure.
What is the expected lifespan of the T650?
No expected service-life estimate is supplied. For a used T650, inspect the engine, hydraulic system, undercarriage, tracks, controls, and service records to assess its condition.
What should a buyer check when purchasing a used Crawler Loaders?
Check the engine operation, hydraulic response, track and undercarriage wear, bucket condition, controls, leaks, and service records. Confirm that the hydrostatic travel system and any auxiliary hydraulics operate correctly, and inspect the machine for damage or excessive wear.
