Bobcat S770 Skid Steer / CTL
Bobcat S770
5+
sold in last yearGeneral overview
The Bobcat S770 is a skid steer loader designed for construction material handling, loading, and general site work. It is powered by a Kubota V3800-DI-TE3 4-cylinder engine with an output of 68 kW (92 hp), and it has a rated operating capacity of 1,519 kg (3,350 lb).
This model has an operating weight of 4,225 kg (9,310 lb) and a width without bucket of 1,831 mm (6 ft), placing it in a compact loader class for maneuvering on job sites. Standard two-speed travel reaches 19 km/h (11.8 mph), and the hydraulic system delivers 87 L/min (23 gpm) at 241.3 bar (3,500 psi). The lift path provides a height to hinge pin of 3,337 mm (10 ft 11 in).
Year
2013, 2022
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
mm
~ in
mm
~ in
mm
~ in
Engine Power
92 hp
Operating Weight
4,225 kg
Rated Operating Capacity
1,519 kg
Dump Height
3,337 mm
Max. speed
19 km/h
Additional specifications
Displacement
3 cu(m)
Speeds
Two-speed (standard)
Fuel tank
90 L
Wheelbase
1,226 mm
Net Power (ISO 9249)
88 hp
Manufacturer and Model
Kubota V3,800-DI-TE3
Pump flow loader
87 L/min
2 Speed High
19 km/h
System Pressure at Couplers
24,131 kPa
Hydraulic Horsepower Flow
46 hp
Length Without Bucket
2,903 mm
Length With Foundry Bucket
3,596 mm
Width Without Bucket
1,831 mm
Height to Top of ROPS
2,065 mm
Height to Hinge Pin
3,337 mm
Dump Height With Foundry Bucket
3,337 mm
Dump Reach With Foundry Bucket
853 mm
Ground Clearance
205 mm
Angle of Departure
25 deg
Front Turn Radius With Foundry Bucket
2,179 mm
Dump Angle (full lift height)
42 deg
Bucket Rollback (ground level)
32 deg
Tipping Load
3,039 kg
Boom Breakout Force With Foundry Bucket
22 kg
Bucket Breakout Force With Foundry Bucket
24 kg
Operating Weight - Rear
4,225 kg
Standard features
12-16.5
Seed spacing
11 mm
Cylinders
4
Bobcat S770 Skid Steer / CTL Listings
Looking for Bobcat S770 Skid Steer / CTL?
See similar listingsCompare Bobcat S770 Skid Steer / CTL to other skid steer / ctl
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
2.0
Rating
Based on ratings and reviews from verified buyers.
Overall rating
1 reviews
5
4
3
2
1
Performance & Productivity
1.0
Reliability & Durability
3.0
Comfort & Ergonomics
2.0
Safety
4.0
Technology & Features
2.0
Bryan Schroeder
We added high-flow and it runs the brush cutter well. It holds its resale value well. Worth noting: the engine layout makes some service tight.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Bobcat S770?
No confirmed market price is supplied for the Bobcat S770. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the Bobcat S770?
Listed strengths include 1,519 kg (3,349 lb) rated operating capacity, 3,337 mm (131.4 in) dump height, two-speed travel with a 19 km/h (11.8 mph) maximum speed, and 87 L/min (23 gpm) loader pump flow.
What type of engine does the S770 use?
The S770 is listed with a Kubota V3800-DI-TE3 engine. It has 4 cylinders and a net power rating under ISO 9249.
How much horsepower does the S770 have?
The listed engine power is 68.6 kW (92 hp). Net Power (ISO 9249) is listed as 65.6 kW (88 hp).
What fuel does the Bobcat S770 use?
The supplied specifications list a 90 L (23.8 US gal) fuel tank, but they do not confirm the fuel type.
What jobs is this Skid Steer Loaders best suited for?
The supplied data supports use where rated operating capacity, dump height, and hydraulic flow matter, including loading and material-handling work. Exact suitability depends on the attachment, worksite conditions, and required operating capacity.
What is the expected lifespan of the S770?
The supplied data does not provide an expected service-life estimate for the S770. Service history, operating conditions, maintenance practices, and the condition of the engine, hydraulics, and structure should be assessed.
What should a buyer check when purchasing a used Skid Steer Loaders?
Inspect service records, engine operation, hydraulic leaks and couplers, pump performance, tire condition, lift arms, bucket or attachment wear, ROPS condition, controls, and signs of structural damage. Confirm that the machine’s capacity and attachments suit the intended work.
