Bobcat S750 Skid Steer / CTL
Bobcat S750
5+
sold in last yearGeneral overview
Bobcat S750 is a skid steer loader used in construction environments for loading, material handling, and other compact-site tasks. It is powered by a 62 kW (85 hp) four-cylinder engine and uses a hydrostatic powertrain with Interim Tier 4 emissions compliance. Produced in the United States in 2012, it fits a conventional loader role within the skid steer category.
With an operating weight of 3,960 kg (8,730 lb), the S750 is sized for medium-duty loader work. It has a rated operating capacity of 1,451 kg (3,200 lb), a tipping load of 2,903 kg (6,400 lb), and a maximum speed of 19 km/h (11.8 mph). Hydraulic output is listed at 87 L/min (23 gpm) with 241.3 bar (3,500 psi) at the couplers, and dump height reaches 3,353 mm (11 ft).
Year
2012
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
3,597 mm
~141.6 in
2,065 mm
~81.3 in
1,880 mm
~74 in
Engine Power
85 hp
Operating Weight
4,033.7 kg
Rated Operating Capacity
1,451 kg
Dump Height
3,353 mm
Max. speed
19 km/h
Additional specifications
Emission standard level
Interim Tier 4
Speeds
Single-speed standard; optional two-speed (high/low)
Fuel tank
90 L
Wheelbase
1,227 mm
Battery Voltage
12
Pump flow loader
87 L/min
2 Speed High
19 km/h
System Pressure at Couplers
24,132 kPa
Hydraulic Horsepower Flow
46 hp
Length Without Bucket
2,903 mm
Length With Foundry Bucket
3,597 mm
Width Without Bucket
1,831 mm
Height to Top of ROPS
2,065 mm
Height to Hinge Pin
3,353 mm
Dump Height With Foundry Bucket
3,353 mm
Dump Reach With Foundry Bucket
800 mm
Dump Reach With Construction Bucket
828 mm
Ground Clearance
185 mm
Angle of Departure
24 deg
Front Turn Radius With Foundry Bucket
2,179 mm
Dump Angle (full lift height)
42 deg
Bucket Rollback (ground level)
30 deg
Tipping Load
2,903 kg
SAE Rated Operating Capacity With Counterweight
1,102 kg
Boom Breakout Force With Foundry Bucket
29 kg
Boom Breakout Force With Construction Bucket
29 kg
Bucket Breakout Force With Foundry Bucket
29 kg
Bucket Breakout Force With Construction Bucket
29 kg
Powertrain Type
Hydrostatic
Operating Weight - Rear
3,960 kg
Standard features
12-16.5
Seed spacing
11 mm
Cylinders
4
Bobcat S750 Skid Steer / CTL Listings
Looking for Bobcat S750 Skid Steer / CTL?
See similar listingsCompare Bobcat S750 Skid Steer / CTL to other skid steer / ctl
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Bobcat S750?
No confirmed market price is supplied for the Bobcat S750. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the Bobcat S750?
Listed strengths include 63.4 kW (85 hp), a rated operating capacity of 1,451 kg (3,199 lb), 3,353 mm (132 in) dump height, and hydrostatic powertrain. The hydraulic system lists 87 L/min (23 gpm) pump flow and 24,132 kPa (3,500.1 psi) pressure at couplers.
What type of engine does the S750 use?
The supplied specifications identify a 4-cylinder engine with an Interim Tier 4 emission standard. They do not confirm the engine manufacturer, model, displacement, or fuel type.
How much horsepower does the S750 have?
The Bobcat S750 is listed with engine power of 63.4 kW (85 hp).
What fuel does the Bobcat S750 use?
The supplied data does not confirm the fuel type. It lists a 90 L (23.8 US gal) fuel tank, but this does not identify the fuel.
What jobs is this Skid Steer Loaders best suited for?
The supplied specifications support evaluating it for loading and material-handling work: rated operating capacity is 1,451 kg (3,199 lb), dump height is 3,353 mm (132 in), and pump flow is 87 L/min (23 gpm). The data does not specify particular job applications.
What is the expected lifespan of the S750?
No expected service-life figure is supplied for the S750. Lifespan depends on maintenance, operating conditions, hours of use, attachment use, and the condition of the engine, hydraulics, and undercarriage components.
What should a buyer check when purchasing a used Skid Steer Loaders?
Inspect service records, engine operation, hydraulic leaks and coupler condition, lift arms and bucket mounting points, tires, controls, ROPS, and safety equipment. Test travel and lift functions, and verify the machine’s configuration and attachments match the listing.
